REAR WHEEL
GS750L 1980 (T) USA (E03)
Rear wheel diagram GS750L 1980 (T) USA (E03)
REAR WHEEL GS750L 1980 (T) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1-1
6411149100
ref: 1-1
64111-49100-12U
WHEEL,REAR
€ 293.50
1-2
6411149110
ref: 1-2
64111-49100-291
WHEEL,REAR
€ 195.50
2
0813362047
ref: 2
BEARING WHEEL REAR(20X47X14)
€ 22.50
3
0815362047
ref: 3
09262-20042
BEARING, LH
€ 21.00
4
0918020062
ref: 4
SPACER(20.5X28X88)
€ 11.50
5
6473349100
ref: 5
SPACER,REAR HUB BEARING
€ 26.50
6
6471149000
ref: 6
64711-4900V
AXLE,REAR
€ 59.00
7
6474045001
ref: 7
64740-45002
SPACER,REAR AXLE
€ 15.00
8
0918020071
ref: 8
SPACER
€ 7.50
9
0831431188
ref: 9
08314-3118A
NUT 18MM
€ 5.00
10
0411140308
ref: 10
04111-4030A
PIN,COTTER
€ 1.50
11
0916019008
ref: 11
WASHER(19X34X4)
€ 3.00
12
6461131001
ref: 12
64611-31003
DRUM,REAR SPROCKET MOUNT
€ 140.00
13
0811363050
ref: 13
09262-25073
BEARING
€ 21.50
14
0928533001
ref: 14
SEAL,OIL(33X62X7)
€ 20.00
15
6465131000
ref: 15
64651-31001
ABSORBER,REAR HUB SHOCK
€ 9.50
16
6972147011
ref: 16
BRACKET,RR,CALIPER
€ 29.00
17
0918020060
ref: 17
SPACER(20X38X12)
€ 6.50
18-1
6141045200
ref: 18-1
61410-31001
ADJUSTER,CHAIN
€ 50.00
18-2
6141045201
ref: 18-2
61410-31001
ADJUSTER,CHAIN
€ 50.00
19
0910408018
ref: 19
09104-08034
BOLT 8X50
€ 3.00
20
0831012088
ref: 20
08310-00087
NUT
€ 2.00
21
6143331000
ref: 21
61433-3100V
SUPPORTER,CHAIN ADJUST
€ 22.50
22
0151708408
ref: 22
01550-08407
BOLT (8X40)
€ 3.50
23
5921018450
ref: 23
DISC,RR BRAKE
€ 446.00
24
0910008094
ref: 24
BOLT(8X30)
€ 2.50
25
0916908016
ref: 25
WASHER
€ 3.50
26
6451145200
ref: 26
SPROCKET,RR(NT:40)
€ 61.50
27
0911910002
ref: 27
09105-10001
BOLT
€ 3.50
28
0831012108
ref: 28
08310-00107
NUT
€ 2.50
29
0916910007
ref: 29
WASHER
€ 7.50
30-1
6510049111
ref: 30-1
TIRE
€ 93.00
30-2
6510049130
ref: 30-2
TIRE
€ 0.00
30-3
6510045235
ref: 30-3
TIRE
€ 153.00
31
6520049100
ref: 31
65200-05A30
TUBE ASSEMBLY,WHEEL,INNER
€ 0.00
32
5541147001
ref: 32
BALANCER,WHEEL
€ 4.00
33
5541247001
ref: 33
BALANCER,WHEEL
€ 3.50
