prices are in EUR
ref
part #
description
quantity
1-1
CARBURETOR ASSEMBLY,LEFT
1-2
CARBURETOR ASSEMBLY,LEFT
2-1
CARBURETOR ASSEMBLY,MIDDLE,LEFT
2-2
CARBURETOR ASSEMBLY,MIDDLE,LEFT
3-1
CARBURETOR ASSEMBLY,MIDDLE,RIGHT
3-2
CARBURETOR ASSEMBLY,MIDDLE,RIGHT
4-1
CARBURETOR ASSEMBLY,RIGHT
4-2
CARBURETOR ASSEMBLY,RIGHT
6
VALVE,PISTON
7
E RING
8
RING
9
RING
10
SPRING
21
SEAL
22
GASKET,THROTTLE SHAFT (NAS)
24
VALVE,THROTTLE(125)
25
GASKET,FLOAT CHAMBER (NAS)
26
JET,PILOT(30)
27
JET,NEEDLE(O-6)
28
O RING
29
JET,MAIN(120)
31-1
FLOAT ASSY
32
VALVE ASSEMBLY,NEEDLE
33
O RING
34
O-RING,NEEDLE VALVE
35
SCREW
37-1
CAP
37-2
CAP
37-2
CAP
38-1
CLIP
38-2
CLIP
38-2
CLIP
40
COVER,DIAPHRAGM
41
CAP,STARTER
44
WASHER
45
HOLDER,GUIDE
46
SPRING
47
WASHER
48
PLUNGER ASSY
49-1
JET,AIR(1.2)
49-2
JET,AIR(1.0)
