THROTTLE BODY

GSXR600 2007 (K7) USA (E03)

Throttle body diagram GSXR600 2007 (K7) USA (E03)

prices are in EUR

ref

part #

description

quantity

1-1

1340501H00
ref: 1-1

BODY ASSY,THRO

€ 1,724.50

1-2

1340501H10
ref: 1-2

BODY ASSY, THROTTLE

€ 1,012.50

1326720E20
ref: 2

SCREW,ADJUST

€ 8.50

13268054A0
ref: 3

SPRING

€ 3.50

1342629G00
ref: 4

SPRING,TORSION

€ 3.50

1342044G00
ref: 5

LEVER ASSY

€ 71.50

1342729G00
ref: 6

PACKING (NAS)

€ 2.50

1342429G00
ref: 7

E RING

€ 2.50

1329529900
ref: 8

O RING,PILOT AIR SCREW

€ 4.00

1360647A00
ref: 9

WASHER

€ 2.00

1326848700
ref: 10

SPRING,THROTTLE SCREW

€ 3.50

1326933E00
ref: 11

SCREW

€ 8.50

1358029G00
ref: 12

SENSOR ASSY

€ 101.50

1358040F30
ref: 13

SENSOR ASSY,TH

€ 188.00

1357529G00
ref: 14

O RING

€ 3.00

1360502F00
ref: 15

SCREW

€ 3.00
