SEAT
GSXR600Z 2003 (K3) USA (E03)
Seat diagram GSXR600Z 2003 (K3) USA (E03)
SEAT GSXR600Z 2003 (K3) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
4510035F00R42
ref: 1
SEAT ASSY
€ 232.00
2
4514912C00
ref: 2
CUSHION,SEAT(40X20X6)
€ 3.00
3
4511233E00
ref: 3
SPACER,SEAT(6.5X10.5X6)
€ 3.50
4-1
4530035F00R42
ref: 4-1
45300-35F20-R42
SEAT ASSEMBLY,PILLION
€ 189.50
4-2
4530035F20R42
ref: 4-2
SEAT ASSY,PILLION
€ 189.50
5
4518035F00R42
ref: 5
BAND ASSY,SEAT(BLACK)
€ 56.00
6
0831610063
ref: 6
08316-1006B
NUT
€ 2.50
7
4521331300
ref: 7
CUSHION
€ 1.50
8
4522020A01
ref: 8
45220-47H00
BRACKET,SEAT SUPPORT,RIGHT
€ 79.50
9
0212206303
ref: 9
02122-0630B
SCREW
€ 2.00
10
4528021F00
ref: 10
CABLE,SEAT LOCK
€ 25.00
11
9570014810
ref: 11
LOCK SET,SEAT
€ 75.50
12
4528814F00
ref: 12
GUIDE,SEAT LOCK CABLE
€ 3.00
13
4528911F00
ref: 13
PLATE,SEAT LOCK ASSY
€ 3.00
