SEAT TAIL BOX (MODEL K2)

GSXR600Z 2003 (K3) USA (E03)

Seat tail box (model k2) diagram GSXR600Z 2003 (K3) USA (E03)

SEAT TAIL BOX (MODEL K2) GSXR600Z 2003 (K3) USA (E03)

SEAT TAIL BOX (MODEL K2) GSXR600Z 2003 (K3) USA (E03)

prices are in EUR

ref

part #

description

quantity

1-1

4555040F100JW
ref: 1-1

BOX,SEAT TAIL(WHITE)

€ 57.50

1-2

4555040F10Y7L
ref: 1-2

BOX,SEAT TAIL(BLACK)

€ 178.00

1-3

4555040F10YC2
ref: 1-3

BOX,SEAT TAIL(BLUE)

€ 57.50

2

4521331300
ref: 2

CUSHION

€ 1.50
