MUFFLER (GT550L

GT550 1973 1974 1975 1976 1977 (K) (L) (M) (A) (B) USA (E03)

Muffler (gt550l diagram GT550 1973 1974 1975 1976 1977 (K) (L) (M) (A) (B) USA (E03)

prices are in EUR

ref

part #

description

quantity

1451034000
ref: 2

PIPE,BAFFLE

€ 73.50

1451034000
ref: 4

PIPE,BAFFLE

€ 73.50

1451036100
ref: 6

PIPE,BAFFLE

€ 47.50

1451036100
ref: 8

PIPE,BAFFLE

€ 47.50

0912805004
ref: 9

BOLT(5X8)

€ 2.00

0832101057
ref: 10

WASHER,LOCK

€ 2.00

1477106090
ref: 11

CONNECTOR,MUFFLER

€ 10.50

0940236708
ref: 12

CLAMP

€ 13.50

0211206207
ref: 13

SCREW

€ 2.00

0150010603
ref: 14

BOLT

€ 3.50

0832101107
ref: 15

WASHER,LOCK

€ 2.00

0832201107
ref: 16

WASHER

€ 2.50

0832201107
ref: 17

WASHER

€ 2.50

0931910009
ref: 18

BUSHING(10X23X35)

€ 7.50

1418134020
ref: 20

GASKET,EXHAUST PIPE (NAS)

€ 8.00

0150008353
ref: 21

BOLT

€ 3.50

0832101087
ref: 22

WASHER,LOCK

€ 2.00

0928043002A
ref: 25

O RING(D:2.6,ID:39.7)

€ 2.50

0944311002
ref: 26

SPRING

€ 4.50

1477033000
ref: 27

DAMPER,MUFFLER SUPPORT BRACKET

€ 15.00

0915910046
ref: 28

NUT (M10X1.25X9)

€ 2.00

0918010038
ref: 29

SPACER(10.1X15X4.8)

€ 5.50

MUFFLER (GT550L

all assemblies
