STAND - FOOTREST
PE175 1978 (C) USA (E03)
Stand - footrest diagram PE175 1978 (C) USA (E03)
STAND - FOOTREST PE175 1978 (C) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
4231041500
ref: 1
STAND,SIDE
€ 31.50
2
0944317007
ref: 2
SPRING
€ 6.50
3
0910010067
ref: 3
BOLT(10X30)
€ 5.00
4
0831022108
ref: 4
08310-00107
NUT
€ 3.50
5
4355029300
ref: 5
FOOTREST,FR,R
€ 15.00
6
4356029300
ref: 6
FOOTREST,FR,L
€ 15.00
7
0920010008
ref: 7
PIN
€ 4.00
8
0411125208
ref: 8
04111-2520A
PIN 25X20
€ 2.50
9
0944815004
ref: 9
SPRING
€ 3.00
10
4210041400
ref: 10
STAND,CENTER
€ 40.50
11
0918010001
ref: 11
SPACER(10.5X16X30)
€ 5.00
12
0110710508
ref: 12
01500-1050A
BOLT (10X50)
€ 7.00
13
0832121108
ref: 13
08321-01107
LOCK WASHER
€ 3.00
14
6231097001
ref: 14
NO PRODUCT DESCRIPTION AVAILABLE
€ 4.50
15
0932110002
ref: 15
CUSHION(11.5X22X20)
€ 3.00
