OIL TANK (E16,E43,MODEL R E15)

PV50 1981 (X) (E01)

Oil tank (e16,e43,model r e15) diagram PV50 1981 (X) (E01)

prices are in EUR

ref

part #

description

quantity

1-1

4461117200
ref: 1-1
E16,E43

TANK,OIL

€ 0.00

1-2

4461117210
ref: 1-2
MODEL R E15

TANK, OIL

€ 0.00

4465105003
ref: 2

CAP,OIL TANK

€ 4.00

4460030832
ref: 3

GASKET SET (NAS)

€ 6.00

4-1

0110706166
ref: 4-1
MODEL D/H

BOLT

€ 2.00

4-2

0911606006
ref: 4-2
MODEL L/M/R

BOLT(6X16)

€ 2.00

0916006006
ref: 5
MODEL D/H

WASHER

€ 2.00

3788017200
ref: 6

SWITCH ASSY, OIL LEVEL

€ 0.00

4464331000
ref: 7

GASKET (NAS)

€ 2.50
