Buy Suzuki RF Parts Online


CARBURETOR (MODEL T/V/W)

RF900R 1995 (S2) (E02 E04 E18 E22 E24 E25 E34 E37)

Carburetor (model t/v/w) diagram RF900R 1995 (S2) (E02 E04 E18 E22 E24 E25 E34 E37)

CARBURETOR (MODEL T/V/W) RF900R 1995 (S2) (E02 E04 E18 E22 E24 E25 E34 E37)
CARBURETOR (MODEL T/V/W) RF900R 1995 (S2) (E02 E04 E18 E22 E24 E25 E34 E37)
CARBURETOR (MODEL T/V/W) RF900R 1995 (S2) (E02 E04 E18 E22 E24 E25 E34 E37)
prices are in EUR
ref
part #
description
quantity
1-1
1320131EA0
ref: 1-1
CARBURETOR ASSY, LH
€ 0.00
1-2
1320131EC0
ref: 1-2
E4
CARBURETOR ASSY, LH
€ 0.00
1-3
1320131ED0
ref: 1-3
E22
CARBURETOR ASSY, LH
€ 0.00
1-4
1320131E72
ref: 1-4
E24
CARBURETOR ASSY, LH
€ 0.00
1-5
1320131EF0
ref: 1-5
E37, P37
CARBURETOR ASSY, LH
€ 0.00
2-1
1320231EA0
ref: 2-1
->13202-31E72
CARBURETOR ASSY, ML
1320231EA0
€ 289.00
2-2
1320231EC0
ref: 2-2
E4
CARBURETOR ASSY, ML
€ 0.00
2-3
1320231ED0
ref: 2-3
E22
CARBURETOR ASSY,ML
€ 0.00
2-4
1320231E72
ref: 2-4
E24
CARBURETOR ASSY, ML
€ 0.00
2-5
1320231EF0
ref: 2-5
E37, P37
CARBURETOR ASSY, ML
€ 0.00
3-1
1320331EA0
ref: 3-1
->13203-31E72
CARBURETOR ASSY, MR
€ 0.00
3-2
1320331EC0
ref: 3-2
E4
CARBURETOR ASSY, MR
€ 0.00
3-3
1320331ED0
ref: 3-3
E22
CARBURETOR ASSY,MR
€ 0.00
3-4
1320331E72
ref: 3-4
E24
CARBURETOR ASSY, MR
€ 0.00
3-5
1320331EF0
ref: 3-5
E37, P37
CARBURETOR ASSY, MR
€ 0.00
4-1
1320431EA0
ref: 4-1
->13204-31E72
CARBURETOR ASSY, RH
€ 0.00
4-2
1320431EC0
ref: 4-2
E4
CARBURETOR ASSY, RH
€ 0.00
4-3
1320431ED0
ref: 4-3
E22
CARBURETOR ASSY,R
€ 0.00
4-4
1320431E72
ref: 4-4
E24
CARBURETOR ASSY, RH
€ 0.00
4-5
1320431EF0
ref: 4-5
E37, P37
CARBURETOR ASSY, RH
€ 0.00
5
1355021E30
ref: 5
RH
SHAFT,THROTTLE
€ 0.00
6
0916908012
ref: 6
ML, MR
WASHER
0916908012
€ 2.00
7
1355321E10
ref: 7
MR
LEVER,THROTTLE
€ 0.00
8
1355747070
ref: 8
GASKET,THROTTLE SHAFT (NAS)
1355747070
€ 4.00
9
1357321E10
ref: 9
MR
SPRING
€ 0.00
10
1357321E00
ref: 10
ML
SPRING
€ 0.00
11
1355021E10
ref: 11
ML
SHAFT,THROTTLE
€ 0.00
12
1355021E00
ref: 12
LH
SHAFT,THROTTLE
1355021E00
€ 37.00
13
0211275163
ref: 13
SCREW
0211275163
€ 2.50
14
0831000087
ref: 14
ML, MR
NUT
0831000087
€ 2.00
15
1355021E20
ref: 15
MR
SHAFT,THROTTLE
€ 76.00
16
1355321E00
ref: 16
ML
LEVER,THROTTLE
€ 0.00
17
1350217E20
ref: 17
COVER,DIAPHRAGM
1350217E20
€ 60.00
18
1350717C01
ref: 18
DIAPHRAGM
1350717C01
€ 24.50
19
1350118E00
ref: 19
VALVE,PISTON
1350118E00
€ 69.00
20
1341731E00
ref: 20
SPRING
1341731E00
€ 8.50
21
1338242A00
ref: 21
RING
1338242A00
€ 3.50
22
1339440D20
ref: 22
E RING
1339440D20
€ 4.50
23
1338747010
ref: 23
RING
1338747010
€ 7.50
24
1338244030
ref: 24
WASHER
1338244030
€ 3.50
25
1357432C00
ref: 25
LH, RH
RING
€ 0.00
26
1338331E20
ref: 26
NEEDLE JET (5DV1)
1338331E20
€ 15.00
27
1325133C00
ref: 27
O RING
1325133C00
€ 10.00
28
1333205A10
ref: 28
GASKET (NAS)
1333205A10
€ 3.50
29
0949400810
ref: 29
JET,NEEDLE(O-9)
0949400810
€ 30.00
30
1333121E40
ref: 30
RING
1333121E40
€ 4.50
31
1360206C20
ref: 31
SCREW
€ 4.00
32
1329433C00
ref: 32
O RING
1329433C00
€ 5.50
33
1341726D00
ref: 33
SPRING
1341726D00
€ 5.50
34
1343247090
ref: 34
WASHER
1343247090
€ 2.50
35
1322021E00
ref: 35
JET BLOCK ASSEMBLY
1322021E00
€ 38.50
36-1
0949122014
ref: 36-1
JET,MAIN(112.5)
0949122014
€ 16.50
36-2
0949123012
ref: 36-2
E22
JET,MAIN(115)
0949123012
€ 11.50
37
1338521E00
ref: 37
HOLDER,JET
1338521E00
€ 25.00
38
1341817C10
ref: 38
HOLDER,GUIDE
1341817C10
€ 14.00
39
1341817C00
ref: 39
CAP,STARTER
1341817C00
€ 5.00
40
1341105320
ref: 40
PLUNGER ASSY
1341105320
€ 18.00
41
0949324013
ref: 41
JET,PILOT AIR(120)
0949324013
€ 15.50
42-1
1325021E00
ref: 42-1
FLOAT/NEEDLE VALVE ASSEMBLY
€ 96.00
42-2
1325031E00
ref: 42-2
E37,P37
FLOAT/NEEDLE VALVE ASSY
1325031E00
€ 96.00
43
0949212008
ref: 43
JET,PILOT(12.5)
0949212008
€ 14.00
44
0949150006
ref: 44
JET,STARTER(50)
0949150006
€ 15.00
45
1325833C00
ref: 45
SEAL
1325833C00
€ 14.50
46
1329529900
ref: 46
O RING,PILOT AIR SCREW
1329529900
€ 4.00
47
1329129900
ref: 47
WASHER
1329129900
€ 2.00
48
1326847070
ref: 48
SPRING
1326847070
€ 5.00
49-1
1327947070
ref: 49-1
SCREW,PILOT
1327947070
€ 11.50
49-2
1327947070
ref: 49-2
E4
SCREW,PILOT
1327947070
€ 11.50
49-3
1327947070
ref: 49-3
E22
SCREW,PILOT
1327947070
€ 11.50
49-4
1327947070
ref: 49-4
E24
SCREW,PILOT
1327947070
€ 11.50
50
1360205A10
ref: 50
SCREW
1360205A10
€ 4.00
51
1337684110
ref: 51
FILTER
€ 6.50
52
1333106C20
ref: 52
RING
1333106C20
€ 5.50
53
1350817C00
ref: 53
CAP
1350817C00
€ 4.50
54
1367105A40
ref: 54
CLIP
1367105A40
€ 4.00
55
1325106C10
ref: 55
O RING
1325106C10
€ 5.00
56
1365151010
ref: 56
LH, RH:1, ML, MR:2
SEAL
1365151010
€ 4.00
57
1360105148
ref: 57
MR
SCREW(5X14)
1360105148
€ 3.00
58
1362731E00
ref: 58
MR
BRACKET
€ 11.50
59
0212205103
ref: 59
MR
SCREW
0212205103
€ 1.00
60
0211205127
ref: 60
SCREW
0211205127
€ 2.50
61
1324713A00
ref: 61
SCREW,DRAIN
1324713A00
€ 5.50
62
1337444080
ref: 62
O-RING,NEEDLE VALVE
1337444080
€ 6.00
63
1355707D00
ref: 63
ML
RING
€ 5.50
64
1365025E01
ref: 64
W/TERMINAL
HEATER ASSY,CARBURETOR(15W)
1365025E01
€ 35.00
64A
1365125E01
ref: 64A
N/TERMINAL
HEATER, CARB.
€ 35.00
65
1365525E00
ref: 65
THERMO SWITCH,CARB HEATER
1365525E00
€ 36.00
66
0940714403
ref: 66
CLAMP(L:125)
0940714403
€ 2.50
