FRAME COVER (MODEL W)

ref

part #

description

quantity

1-1

4710031E5022U
ref: 1-1

COVER ASSY,FRAME,R(MAROON)

€ 389.00

1-2

4710031E5033J
ref: 1-2

COVER ASSY,FRAME,R(BLACK)

€ 343.00

2

4711731E00
ref: 2

SHIELD,FRAME COVER HEAT

€ 32.50

3

6813031E00F3H
ref: 3

TAPE SET,FRAME COVER S

€ 94.00

4-1

6813531E00G6M
ref: 4-1
FOR 22U

TAPE, RH

€ 16.00

4-2

6813531E00G7U
ref: 4-2
FOR 33J

TAPE, RH

€ 16.00

5-1

6813131E00J8N
ref: 5-1
FOR 22U

EMBLEM,FRAME COVER

€ 37.00

5-2

6813131E00C9Y
ref: 5-2
FOR 33J

EMBLEM

€ 37.00

6-1

4720031E5022U
ref: 6-1

COVER, FRAME LH (MAROON)

€ 364.00

6-2

4720031E5033J
ref: 6-2

COVER ASSY,FRAME,L(BLACK)

€ 355.50

7

4721731E00
ref: 7

SHIELD,FRAME COVER HEAT,L

€ 29.00

8

6814031E00F3H
ref: 8

TAPE SET,FRAME COVER STRIPE,L

€ 93.50

9-1

6814531E00G6M
ref: 9-1
FOR 22U

TAPE,FRAME COVER,L

€ 16.00

9-2

6814531E00G7U
ref: 9-2
FOR 33J

TAPE, LH

€ 16.00

10-1

6813131E00J8N
ref: 10-1
FOR 22U

EMBLEM,FRAME COVER

€ 37.00

10-2

6813131E00C9Y
ref: 10-2
FOR 33J

EMBLEM

€ 37.00

11

0214205123
ref: 11

SCREW 5X12

€ 1.50

12

0916105017
ref: 12

WASHER(5.2X14X1.5)

€ 3.00

13

4751131E00
ref: 13

COVER,INNER,RIGHT

€ 14.50

14

4761131E00
ref: 14

COVER,INNER,L

€ 10.00

15

0354114123
ref: 15

SCREW

€ 2.00

16

4719121E00
ref: 16

BRACKET,FRAME COVER,R

€ 4.50

17

4719221E00
ref: 17

BRACKET,FRAME COVER,L

€ 6.00

18

0932008018
ref: 18

CUSHION

€ 4.00

19

0911606131
ref: 19

BOLT(6X25)

€ 2.00

20

4716121E00
ref: 20

CUSHION,FRAME COVER FR

€ 7.50

21

0918006265
ref: 21

SPACER(6.5X9X11)

€ 4.50

22

0932008061
ref: 22

CUSHION

€ 4.00

23-1

4731131E0022U
ref: 23-1

COVER,FRAME CTR

€ 50.50

23-2

4731131E0033J
ref: 23-2

COVER,FRAME CTR

€ 38.50

24

4719321E00
ref: 24

BRACKET,RR COMBINATION LAMP

€ 6.50

25

0214205123
ref: 25

SCREW 5X12

€ 1.50

26

0914805021
ref: 26

NUT

€ 1.50

27

0354114123
ref: 27

SCREW

€ 2.00

28

0324115163
ref: 28

SCREW

€ 2.00

all assemblies
