MUFFLER

ref

part #

description

quantity

1

1418101D00
ref: 1

GASKET,EXHAUST PIPE (NAS)

€ 8.00

2

1419522D00
ref: 2

FLANGE,EXHAUST FITING

€ 54.50

3

0142108305
ref: 3

STUD BOLT

€ 2.00

4

0836135085
ref: 4

NUT

€ 1.50

5-1

1431019D02
ref: 5-1

BODY, MUFFLER, 1ST

€ 472.50

5-2

1431019D20
ref: 5-2
E15

BODY, MUFFLER, 1ST

€ 0.00

5-3

1431019D30
ref: 5-3
MODEL N/P E18

BODY, MUFFLER, 1ST

€ 913.00

5-4

1431019D31
ref: 5-4
MODEL R E18

BODY, MUFFLER, 1ST

€ 913.00

5-5

1431019D60
ref: 5-5
RG125FUN/FUP E2

BODY, MUFFLER, 1ST

€ 0.00

5-6

1431019D61
ref: 5-6
RG125FUR E2

BODY, MUFFLER, 1ST

€ 0.00

5-7

1431019D70
ref: 5-7
E17, RG125FUN/FUP E4

BODY, MUFFLER, 1ST

€ 0.00

5-8

1431019D71
ref: 5-8
RG125FUR E4

BODY, MUFFLER, 1ST

€ 0.00

6-1

1433019D01
ref: 6-1

BODY,MUFFLER 2

€ 259.00

6-2

1433019D10
ref: 6-2
E15

MUFFLER ASSY, 2ND

€ 0.00

6-3

1433019D20
ref: 6-3
E18

MUFFLER ASSY, 2ND

€ 256.00

7-1

0940246501
ref: 7-1

CLAMP

€ 6.50

7-2

0940240501
ref: 7-2
E18

CLAMP

€ 7.00

8-1

1477103D00
ref: 8-1

CONNECTOR,2ND MUFFLER

€ 26.00

8-2

1477119D30
ref: 8-2
MODEL N/P E18

CONNECTOR, MUFFLER

€ 48.00

8-3

1477119D31
ref: 8-3
MODEL R E18

CONNECTOR,2ND MUFFLER

€ 48.00

9

0911808078
ref: 9

BOLT 8X35

€ 4.50

10

0712008357
ref: 10

BOLT

€ 3.50

11-1

0831616085
ref: 11-1
MODEL N/P

NUT 8MM

€ 3.00

11-2

0831610083
ref: 11-2
MODEL R

NUT

€ 3.00

12

0831931085
ref: 12

NUT

€ 2.50

13

0916008067
ref: 13

WASHER

€ 2.00

14

0918008151
ref: 14

SPACER(8.6X12X17.5)

€ 6.00

15-1

0932012043
ref: 15-1
MODEL N

CUSHION

€ 8.00

15-2

0932012033
ref: 15-2
MODEL P/R

CUSHION

€ 52.00

all assemblies
