GEAR SHIFTING
RM125 1988 (J) USA (E03)
Gear shifting diagram RM125 1988 (J) USA (E03)
GEAR SHIFTING RM125 1988 (J) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
2521141301
ref: 1
FORK,GEAR SHIFT NO.1
€ 71.50
2-1
2522114500
ref: 2-1
25221-14501
FORK,GEAR SHIFT NO.2
€ 65.00
2-2
2522114501
ref: 2-2
FORK,GEAR SHIFT NO.2
€ 65.00
3-1
2523114500
ref: 3-1
25231-14X01
FORK,GEAR SHIFT NO.3
€ 23.50
3-2
2523114501
ref: 3-2
25231-14X01
FORK,GEAR SHIFT NO.3
€ 23.50
4
2541114500
ref: 4
25411-20A11
SHAFT,GEAR SHIFT FORK
€ 14.50
5
2542114500
ref: 5
SHAFT,GEAR SHIFT FORK
€ 13.50
6
2531014501
ref: 6
25310-14502
CAM,GEAR SHIFT
€ 42.50
7
2532231301
ref: 7
25322-31310
GEAR,GEARSHIFT CAM DRIVE
€ 14.50
8
2532334201
ref: 8
PAWL,GEAR SHIFT NO.1
€ 6.00
9
2532434201
ref: 9
PAWL,GEAR SHIFT NO.2
€ 6.00
10
0926105003
ref: 10
PIN(5X8)
€ 1.50
11
0944004003
ref: 11
SPRING
€ 1.50
12
2533111001
ref: 12
LIFTER,GEAR SHIFT PAWL
€ 2.50
13
0212206128
ref: 13
02122-06127
SCREW
€ 3.00
14
2534114500
ref: 14
GUIDE,GEAR SHIFT CAM
€ 8.50
15
0212206128
ref: 15
02122-06127
SCREW
€ 3.00
16
2538100B00
ref: 16
PLATE,GEAR SHIFT CAM STOPPER
€ 10.50
17
0422104089
ref: 17
PIN
€ 1.50
18
2535014501
ref: 18
STOPPER,GEAR SHIFTING
€ 7.50
19
0944308036
ref: 19
SPRING
€ 4.00
20
0922304001
ref: 20
RIVET
€ 1.50
21
0926341001
ref: 21
09263-41002
BEARING
€ 32.50
22
0811369030
ref: 22
BEARING
€ 14.00
23
2551001B00
ref: 23
25510-01BV0
SHAFT COMP,GEAR SHIFTING
€ 73.50
24
0918012083
ref: 24
SPACER(12X20X15.3)
€ 2.50
25
0944426017
ref: 25
SPRING
€ 5.00
26
0928512002
ref: 26
09285-12006
OIL SEAL
€ 7.00
27
2567101000
ref: 27
25671-01011
STOPPER,GEAR SHIFT CAM
€ 3.00
28
2560014500
ref: 28
LEVER ASSY,GEAR SHIFT
€ 69.50
29
0151706307
ref: 29
01550-06307
BOLT
€ 2.00
30
0918012115
ref: 30
CUSHION
€ 8.50
