EXHAUST VALVE

ref

part #

description

quantity

1-1

1125428C00
ref: 1-1
MODEL K/M

VALVE,EXHAUST,RIGHT

€ 142.50

1-2

1125428C20
ref: 1-2
MODEL L/N

VALVE,EXHAUST,R

€ 119.50

2-1

1125528C00
ref: 2-1
MODEL K/M

VALVE,EXHAUST,L

€ 126.00

2-2

1125528C20
ref: 2-2
MODEL L/N

VALVE,EXHAUST,L

€ 143.00

3-1

1126128C01
ref: 3-1
MODEL K/M

GUIDE,EXHAUST VALVE,R

€ 140.50

3-2

1126128C20
ref: 3-2
MODEL L/N

GUIDE,EXHAUST VALVE,R

€ 149.00

4-1

1126228C01
ref: 4-1
MODEL K/M

GUIDE,EXHAUST VALVE,L

€ 140.00

4-2

1126228C20
ref: 4-2
MODEL L/N

GUIDE,EXHAUST VALVE,L

€ 151.50

5-1

0211215128
ref: 5-1
MODEL K

SCREW

€ 1.50

5-2

0211215128
ref: 5-2
MODEL L/M/N

SCREW

€ 1.50

6

1126326C00
ref: 6

HOLDER,EXHAUST VALVE

€ 13.50

7

1125301B31
ref: 7

PIN,EXHAUST VALVE 48.5MM

€ 20.50

8

1125928C00
ref: 8

SHAFT,EXHAUST VALVE

€ 50.50

9

1126400B23
ref: 9

ARM,EXHAUST VALVE SHAFT

€ 17.00

10

0913406011
ref: 10

SCREW

€ 4.50

11

1125827C00
ref: 11

CAP,EXHAUST VALVE

€ 52.00

12

0928023002
ref: 12

O RING(D:1.9,ID:22.6)

€ 2.50

13

1126500B21
ref: 13

RETAINER,EXHAUST VALVE

€ 2.50

14

0211205128
ref: 14

SCREW

€ 2.50

15-1

0944416005
ref: 15-1
MODEL K/L

SPRING

€ 4.00

15-2

0944416007
ref: 15-2
MODEL M/N

SPRING

€ 6.00

16

1126900B20
ref: 16

SPACER,EXHAUST VALVE SPRING

€ 19.00

17-1

0211206087
ref: 17-1
MODEL K/L

SCREW

€ 2.00

17-2

0154706107
ref: 17-2
MODEL M/N

BOLT

€ 1.50

18

0821206201
ref: 18

WASHER

€ 1.50

19

1126700B20
ref: 19

LEVER,EXHAUST VALVE NO

€ 5.50

20

0944415008
ref: 20

SPRING

€ 6.00

21

1126801B00
ref: 21

SPACER,EXHAUST VALVE

€ 8.50

22-1

1126600B20
ref: 22-1
MODEL K

LEVER,EXHAUST VALVE NO

€ 3.50

22-2

1126628C10
ref: 22-2
MODEL L/M/N

LEVER,EXHAUST VALVE NO.1

€ 22.50

23

0113405126
ref: 23

BOLT

€ 2.00

24

0916005017
ref: 24

WASHER (5.5X16X1.2)

€ 2.50

25

1267028C00
ref: 25
MODEL K

GOVERNOR ASSEMBLY,EXHAUST

€ 82.50

26

1267028C10
ref: 26
MODEL L/M/N

GOVERNOR ASSY,EXHAUST VALVE

€ 61.00

27

0926310002
ref: 27

BEARING(10X22X2.8)

€ 8.50

28

1268001820
ref: 28

ACTUATOR,EXHAUST VALVE

€ 47.50

29

0611106003
ref: 29

BALL

€ 1.50

30

1268200B20
ref: 30

STARTER,EXHAUST VALVE ACTUATOR

€ 25.00

31

0912005003
ref: 31

SCREW(5X10)

€ 2.00

32

0938019003
ref: 32

CIRCLIP

€ 2.50

33

0918119004
ref: 33

SHIM(19.1X25X0.3)

€ 4.00

34

0916419001
ref: 34

WASHER

€ 7.00

35

0926208005
ref: 35

BEARING(8X22X7)

€ 12.50

36-1

1268528C00
ref: 36-1
MODEL K

ROD,EXHAUST VALVE

€ 3.00

36-2

1268528C10
ref: 36-2
MODEL L/M/N

ROD,EXHAUST VALVE

€ 6.00

37

1268601B00
ref: 37

BUSH,EXHAUST VALVE ROD NO.1

€ 2.00

38

1268701B00
ref: 38

BUSH,EXHAUST VALVE ROD NO.2

€ 2.00
