RADIATOR
RM250 2004 (K4) USA (E03)
Radiator diagram RM250 2004 (K4) USA (E03)
RADIATOR RM250 2004 (K4) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
1771037F00
ref: 1
RADIATOR,WATER,R
€ 577.00
1A
0914806015
ref: 1A
NUT
€ 3.50
2
1773012C20
ref: 2
17730-08J00
CAP COMP,RADIATOR
€ 40.00
3
093515080300A
ref: 3
09351-50803-00B
HOSE(5X8X1000)
€ 10.00
4
1772037F00
ref: 4
RADIATOR,WATER,L
€ 620.50
4A
0914806015
ref: 4A
NUT
€ 3.50
5
1778719A00
ref: 5
CUSHION,RADIATOR LWR
€ 3.50
6
0154706253
ref: 6
01547-0625B
SCREW
€ 2.50
6A
0911606186
ref: 6A
BOLT(6X25)
€ 2.50
7
0916006114
ref: 7
WASHER(6.5X24X1.2)
€ 2.00
8
0918006243
ref: 8
SPACER(6.5X10.5X14.1)
€ 4.50
9
1785137F00
ref: 9
HOSE,RADIATOR INLET
€ 15.50
10
1785237F00
ref: 10
HOSE,RADIATOR OUTLET
€ 15.00
11-1
1785336F00
ref: 11-1
HOSE,RADIATOR JOINT
€ 4.50
11-2
1785336F10
ref: 11-2
HOSE,RADIATOR JOINT NO.1
€ 4.50
11-3
1785337F10
ref: 11-3
17853-36F00
HOSE,RADIATOR
€ 4.50
12
0940228511
ref: 12
CLAMP
€ 8.50
13
0940222511
ref: 13
CLAMP
€ 6.00
14-1
1776137F00YR1
ref: 14-1
COVER,RADIATOR,R
€ 20.50
14-2
1776137F00YU1
ref: 14-2
17761-37F10-YU1
COVER,RDTR,R
€ 91.50
14-3
1776137F10YU1
ref: 14-3
COVER,RADIATOR,R(YELLOW)
€ 91.50
15-1
1776237F00YR1
ref: 15-1
COVER,RADIATOR,L
€ 20.50
15-2
1776237F00YU1
ref: 15-2
17762-37F10-YU1
COVER,RDTR,L
€ 32.00
15-3
1776237F10YU1
ref: 15-3
COVER,RADIATOR,L(YELLOW)
€ 32.00
16-1
0916905021
ref: 16-1
09169-05024
WASHER (5X14X1)
€ 2.00
16-2
0916906054
ref: 16-2
09169-06053
WASHER
€ 2.00
16-3
6923237F00
ref: 16-3
69232-37F01
WASHER,RR BRAK
€ 7.50
17-1
0214205127
ref: 17-1
SCREW
€ 1.50
17-2
0910306233
ref: 17-2
BOLT(6X12)
€ 2.00
18-1
0916906054
ref: 18-1
09169-06053
WASHER
€ 2.00
18-2
6923237F00
ref: 18-2
69232-37F01
WASHER,RR BRAK
€ 7.50
19-1
0154706123
ref: 19-1
01547-0612B
BOLT
€ 2.00
19-2
0910306233
ref: 19-2
BOLT(6X12)
€ 2.00
20-1
1783137E11
ref: 20-1
LOUVER,RADIATOR
€ 11.50
20-2
1783137F00
ref: 20-2
LOUVER,RADIATOR
€ 17.50
21
6866037F00DY9
ref: 21
TAPE, RADIATOR COVER RH
€ 65.50
22
6867037F00DY9
ref: 22
TAPE, RADIATOR COVER LH
€ 80.00
23
6866037F10GY7
ref: 23
TAPE,RADIATOR COVER,R
€ 50.50
24
6867037F10GY7
ref: 24
TAPE,RADIATOR COVER,L
€ 94.00
25
6866037F20KH2
ref: 25
TAPE, RADIATOR COVER RH
€ 119.50
26
6867037F20KH2
ref: 26
TAPE,RADIATOR COVER,L
€ 64.50
27
6866137F00GY8
ref: 27
EMBLEM,SUZUKI
€ 15.50
28
6866037F30NV1
ref: 28
TAPE,RADIATOR COVER,R
€ 61.50
29
6867037F30NV1
ref: 29
TAPE,RADIATOR COVER,L
€ 61.50
30
6866037F40YHB
ref: 30
TAPE,RADIATOR COVER,R
€ 58.00
31
6867037F40YHB
ref: 31
TAPE, RADIATOR COVER LH
€ 95.50
32
6866037F50CET
ref: 32
68660-37F51-CET
TAPE, RADIATOR COVER RH
€ 122.50
33
6867037F50CET
ref: 33
68670-37F51-CET
TAPE, RADIATOR COVER LH
€ 122.50
