REAR SWINGING ARM
SV650A 2006 (K6) USA (E03)
Rear swinging arm diagram SV650A 2006 (K6) USA (E03)
REAR SWINGING ARM SV650A 2006 (K6) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1-1
6100017G00
ref: 1-1
SWINGINGARM ASSY,RR
€ 1,051.50
1-2
6100017G10
ref: 1-2
SWINGINGARM ASSY,RR
€ 1,103.00
1-3
6100017G20
ref: 1-3
SWINGINGARM ASSY,RR
€ 1,165.50
1-4
6100017G30
ref: 1-4
SWINGINGARM ASSY,RR
€ 1,084.00
1-5
6100017G40YAP
ref: 1-5
SWINGINGARM ASSY,RR
€ 1,084.00
1-6
6100017G50YAP
ref: 1-6
SWINGINGARM ASSY,RR
€ 1,273.50
1-7
6100017G60YAP
ref: 1-7
SWINGINGARM ASSY,RR
€ 951.00
2
0926325059
ref: 2
BEARING(25X33X35)
€ 35.00
3
0918020113
ref: 3
SPACER(20.8X27.2X161)
€ 21.00
4
0926317039
ref: 4
BEARING(17X24X20)
€ 18.00
5
6125131E00
ref: 5
SPACER,RR SWGARM PIVOT BERRING
€ 16.00
6
6121117G00
ref: 6
SHAFT,RR SWINGINGARM PIVOT
€ 86.50
7
6121419F00
ref: 7
61214-19F10
NUT,REAR SWING ARM PIVOT BOLT
€ 8.50
8
083193118A
ref: 8
NUT
€ 17.50
9
6127317G00
ref: 9
BUFFER,CHAIN TOUCH DEFENSE
€ 30.50
10
0911606152
ref: 10
BOLT(6X20)
€ 2.00
11
0918006306
ref: 11
SPACER(6.5X9X5)
€ 2.00
12
6131019F00
ref: 12
CASE,CHAIN
€ 58.50
13
0913906083
ref: 13
SCREW(6X16)
€ 2.50
14
6141017G00
ref: 14
ADJUSTER,CHAIN
€ 31.50
15
6142117G00
ref: 15
GUIDE,CHAIN ADJUSTER
€ 25.00
16
0831931087
ref: 16
NUT
€ 2.50
