HANDLEBAR (SV650/A)
SV650A 2009 (K9) USA (E03)
Handlebar (sv650/a) diagram SV650A 2009 (K9) USA (E03)
HANDLEBAR (SV650/A) SV650A 2009 (K9) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
5611117G10
ref: 1
HANDLEBAR
€ 109.50
2
5620016821
ref: 2
BALANCER SET,HANDLEBAR
€ 25.50
3
021220660B
ref: 3
SCREW
€ 3.00
4
5627210G00
ref: 4
EXPANDER,HANDLE BALANCER
€ 3.00
5
0916006131
ref: 5
WASHER(6.5X16X4)
€ 2.50
6
5627310G10
ref: 6
NUT,HANDLE BALANCER
€ 6.50
7
5650017G30
ref: 7
MIRROR ASSY,RR VIEW,R
€ 74.50
8
5660017G30
ref: 8
MIRROR ASSY,RR VIEW,L
€ 265.00
8A
5652428601
ref: 8A
CAP
€ 4.00
9
5820017G00
ref: 9
CABLE ASSY,CLUTCH
€ 34.50
10
5862017G00
ref: 10
GUIDE,CLUTCH CABLE
€ 19.50
11
5830016GA0
ref: 11
CABLE ASSY,THROTTLE NO.1
€ 30.00
12
5830016GB0
ref: 12
CABLE ASSY,THROTTLE NO.2
€ 31.00
13
5862116GC0
ref: 13
GUIDE,CABLE L
€ 15.50
14
015500612B
ref: 14
BOLT
€ 2.50
15
5862016G30
ref: 15
GUIDE,THROTTLE CABLE
€ 18.00
16
5862016G20
ref: 16
GUIDE,THROTTLE CABLE NO.2
€ 16.00
