FRAME - OIL TANK - TM250 1975 (M) USA (E03)

ref

part #

description

quantity

1-1

4110030600019
ref: 1-1

FRAME

€ 0.00

1-2

4110033101019
ref: 1-2

FRAME

€ 0.00

1-3

4110030200019
ref: 1-3

FRAME

€ 0.00

1-4

4110030201019
ref: 1-4

FRAME

€ 0.00

2

9491016500
ref: 2

PLATE SET,FRONT

€ 19.00

3

9495028300
ref: 3

NO PRODUCT DESCRIPTION AVAILABLE

€ 2.50

4

0214106127
ref: 4
02142-06127

SCREW 6X12

€ 1.50

5-1

0946200055A
ref: 5-1

BAND

€ 4.00

5-2

0946200057
ref: 5-2

BAND

€ 2.00

6

6816916500
ref: 6

EMBLEM,FRONT NUMBER PLATE

€ 3.50

7

9491216500
ref: 7

PLATE,NUMBER,FRONT

€ 10.00

8

0832121068
ref: 8
08321-01067

LOCK WASHER

€ 2.50

9

0916906010
ref: 9

WASHER

€ 3.00

10

0111206128
ref: 10
01500-06127

BOLT

€ 2.00

11

0214106127
ref: 11
02142-06127

SCREW 6X12

€ 1.50

12

6813930100
ref: 12

TAPE,FRAME COVER

€ 0.00

13

6817126000
ref: 13

EMBLEM,CCIS

€ 4.00

14

4461116502
ref: 14

TANK,OIL

€ 31.50

15

0934405005
ref: 15
09351-50803-00B

HOSE

€ 10.00

16

0940108401
ref: 16

CLIP

€ 1.50

17

5122151010
ref: 17

CAP, OIL TANK

€ 3.50

18

4466132100
ref: 18
51222-16500

GASKET,OIL TANK (NAS)

€ 3.50

19

0940108401
ref: 19

CLIP

€ 1.50

20

0940709301
ref: 20

CLAMP

€ 6.00

21

5122316500
ref: 21
51222-16500

GASKET,OIL TANK CAP

€ 3.50

22

0932010008
ref: 22

CUSHION

€ 2.50

23

0918006030
ref: 23
09180-06310

SPACER (6.8X10X10)

€ 2.00

24

0111206208
ref: 24
01500-06207

BOLT

€ 2.00

25

0832121068
ref: 25
08321-01067

LOCK WASHER

€ 2.50

26

0916006027
ref: 26
09160-06077

WASHER (6.5X20X1.2)

€ 2.00

27

6832816500
ref: 27

LABEL

€ 1.50

28-1

0980000133
ref: 28-1

NO PRODUCT DESCRIPTION AVAILABLE

€ 8.00

28-2

0980000142
ref: 28-2
09800-00028

09800-00028

€ 8.00

28-3

0980000028
ref: 28-3

NO PRODUCT DESCRIPTION AVAILABLE

€ 8.00
