prices are in EUR
ref
part #
description
quantity
1
SWING ARM ASSEMBLY,REAR
2
SWING ARM ASSEMBLY,REAR
3
SWING ARM ASSEMBLY,REAR
4-1
BUSHING
4-2
BUSHING
5-1
SPACER,SWING ARM,CENTER
5-2
SPACER,SWING ARM,CENTER
6
NIPPLE,GREASE
7
SHAFT,REAR SWING ARM
9-1
NUT
9-2
NUT
10-1
BUFFER,CHAIN TOUCH DEFLECTOR
10-2
BUFFER,CHAIN TOUCH DEFLECTOR
11-1
WASHER
11-2
WASHER
12-1
SPACER,RR SWGARM PIVOT
12-2
SPACER,REAR SWING ARM
13-1
COVER,SWGARM BUSH DUST SEAL
13-2
COVER
14-1
O RING(D:2,ID:24.5)
14-2
O RING(D:3,ID:29.5)
15-1
WASHER(12.5X24X2.3)
15-2
WASHER(14.5X29X2.3)
20
LOCK WASHER
21
ABSORBER ASSEMBLY,REAR SHOCK
22-1
ABSORBER ASSEMBLY,REAR SHOCK
22-2
ABSORBER ASSEMBLY,REAR SHOCK
23
NUT
24
WASHER
25
WASHER
26-1
NO PRODUCT DESCRIPTION AVAILABLE
26-2
NO PRODUCT DESCRIPTION AVAILABLE
27
BOLT
28
LOCK WASHER
29
SPACER(6.5X12X6.9)
30
ROLLER,CHAIN GUIDE
31
NUT (6MM)
32
SPACER
33-2
TENSIONER,CHAIN
34
WASHER
35-2
WASHER
36
WASHER (6.5X24X1.6)
37
LOCK WASHER
39-1
WASHER (6.5X24X1.6)
39-2
WASHER
40
LOCK WASHER
41-2
BOLT(12X33)
42-1
TORQUE LINK,REAR
42-2
TORQUE LINK,REAR
43-1
BOLT, REAR TORQUE LINK
43-1
BOLT, REAR TORQUE LINK
43-2
BOLT(8X22.5)
44
NUT
45
LOCK WASHER
46-1
RETAINER,SNAP
46-2
CLIP
47-2
BOLT(10X32.5)
49
LOCK WASHER
50
WASHER (12.5X24X1.6)
51-1
SPRING,RETAINER
51-2
CLIP
