HANDLEBAR
TS125 1981 (X) USA (E03)
Handlebar diagram TS125 1981 (X) USA (E03)
HANDLEBAR TS125 1981 (X) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1-1
5611048500291
ref: 1-1
56110-48501-291
HANDLEBAR
€ 59.50
1-2
5611048530
ref: 1-2
HANDLEBAR
€ 34.00
2
5811048500
ref: 2
CABLE,FR BRAKE
€ 35.50
3
0920006013
ref: 3
PIN(L:13.5)
€ 2.00
4
0411120158
ref: 4
04111-2015A
PIN
€ 1.50
5-1
5862132400
ref: 5-1
58621-40401
GUIDE,CABLE
€ 3.50
5-2
5862140401
ref: 5-2
GUIDE,CABLE
€ 3.50
6
0211206108
ref: 6
02112-06107
SCREW
€ 1.50
7
0832121068
ref: 7
08321-01067
LOCK WASHER
€ 2.50
8
5862030501
ref: 8
34930-05203
GUIDE,CABLE
€ 16.00
9
0110708128
ref: 9
01500-08127
BOLT 8X12
€ 2.50
10
0832121088
ref: 10
08321-01087
LOCK WASHER
€ 2.00
11
0832211088
ref: 11
08322-01087
WASHER
€ 2.00
12
5820048000
ref: 12
58200-46090
CABLE ASSEMBLY,CLUTCH
€ 19.00
13
0920006011
ref: 13
PIN(L:15)
€ 2.50
14
0411120158
ref: 14
04111-2015A
PIN
€ 1.50
15
5862648500
ref: 15
CLAMP
€ 7.50
16
3494930002
ref: 16
CLIP
€ 15.50
17
0211206108
ref: 17
02112-06107
SCREW
€ 1.50
18
5830048001
ref: 18
58300-48401
CABLE ASSEMBLY,THROTTLE
€ 32.00
19
0928707002
ref: 19
SEAL,DUST(7X18X30)
€ 2.50
20
0940711301
ref: 20
09407-18301
CLAMP L:110
€ 6.00
21
5839927100
ref: 21
PROTECTOR,CABLE
€ 10.50
22-1
5650045012
ref: 22-1
56500-45013
MIRROR ASSEMBLY,RIGHT
€ 72.50
22-2
5660045012
ref: 22-2
56600-45013
MIRROR ASSEMBLY,LEFT
€ 73.00
23
5191025310
ref: 23
51910-25311
LOCK ASSEMBLY,STEERING
€ 22.50
24
0211205128
ref: 24
02112-05127
SCREW
€ 2.50
25
0832121058
ref: 25
08321-0105A
LOCK WASHER
€ 2.00
26
5163128000
ref: 26
NUT,STEERING STEM(25X44X10)
€ 12.50
27
5161120002
ref: 27
RACE,STEERING INNER UPR
€ 5.50
28
5161133002
ref: 28
LACE,STEERING INNER LWR
€ 7.00
29
5162128000
ref: 29
RACE,STEERING OUTER UPR
€ 7.00
30
0611106003
ref: 30
BALL
€ 1.50
31
0611108003
ref: 31
BALL
€ 1.50
32
5164325001
ref: 32
DUST SEAL,STEERING UPR
€ 4.50
33
5617148501
ref: 33
56171-48502
COVER,STEERING HEAD
€ 14.00
34
0211206128
ref: 34
02112-06127
SCREW 6X12
€ 2.00
35
0832221068
ref: 35
08322-01067
WASHER
€ 2.00
36
3638848500
ref: 36
36388-48501
CAP,PILOT BOX BOLT
€ 4.50
