Buy Suzuki VS Parts Online


STAND - REAR BRAKE

VS1400GLP BOULEVARD S83 2008 (K8) CALIFORNIA (E33)

Stand - rear brake diagram VS1400GLP BOULEVARD S83 2008 (K8) CALIFORNIA (E33)

STAND - REAR BRAKE VS1400GLP BOULEVARD S83 2008 (K8) CALIFORNIA (E33)
STAND - REAR BRAKE VS1400GLP BOULEVARD S83 2008 (K8) CALIFORNIA (E33)
STAND - REAR BRAKE VS1400GLP BOULEVARD S83 2008 (K8) CALIFORNIA (E33)
prices are in EUR
ref
part #
description
quantity
1-1
4231038B01
ref: 1-1
STAND,PROP
4231038B01
€ 129.00
1-2
4231038B90
ref: 1-2
STAND,PROP
4231038B90
€ 141.50
2
0944316014
ref: 2
SPRING
0944316014
€ 8.50
3
0944322007
ref: 3
SPRING
0944322007
€ 7.00
4
4234138B01
ref: 4
BOLT,PROP STAND
4234138B01
€ 9.00
5
0925008014
ref: 5
CAP(OD:12)
0925008014
€ 3.50
6
0918115158
ref: 6
SHIM(15X24X0.5)
0918115158
€ 2.50
7
0914010044
ref: 7
NUT
0914010044
€ 2.50
8
4310038B00
ref: 8
PEDAL ASSY,BRAKE
4310038B00
€ 81.50
9
0944310033
ref: 9
SPRING
0944310033
€ 3.50
10
0912806044
ref: 10
SCREW(6X10)
0912806044
€ 1.50
11
4351938B01
ref: 11
BRACKET,BRAKE PEDAL BOSS
4351938B01
€ 76.50
12
4312038B02
ref: 12
ARM,RR BRAKE
4312038B02
€ 92.50
13
0912505070
ref: 13
SCREW(5X14)
0912505070
€ 3.00
14
0831000057
ref: 14
NUT
0831000057
€ 2.50
15
4327138B00
ref: 15
LINK,BRAKE PEDAL
4327138B00
€ 44.00
16
0916006036
ref: 16
WASHER(6.5X18X1.5)
0916006036
€ 1.50
17
4327238B00
ref: 17
NUT,BRAKE PEDAL LINK
4327238B00
€ 15.50
18
0925005008
ref: 18
CAP(OD:10)
0925005008
€ 5.00
19
0920913008
ref: 19
PIN
0920913008
€ 5.50
20
0944009029
ref: 20
SPRING
0944009029
€ 4.00
21
0154706167
ref: 21
BOLT
0154706167
€ 2.00
