MUFFLER
VS700GLP INTRUDER 1990 (L) USA (E03)
Muffler diagram VS700GLP INTRUDER 1990 (L) USA (E03)
MUFFLER VS700GLP INTRUDER 1990 (L) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
1415038A00
ref: 1
14150-38A01
PIPE,EXHAUST
€ 193.50
2
1416038A01
ref: 2
14160-38A02
PIPE,EXHAUST
€ 202.00
3-1
1418138A00
ref: 3-1
14181-45C00
GASKET,EXHAUST PIPE (NAS)
€ 6.50
3-2
1418145C00
ref: 3-2
GASKET,EXHAUST PIPE (NAS)
€ 6.50
4
1418238A01
ref: 4
14182-38A02
CLAMP,EXHAUST PIPE
€ 21.00
5
0910408026
ref: 5
BOLT(8X35)
€ 4.00
6
1477105A01
ref: 6
14771-05A02
CONNECTOR,MUFFLER
€ 21.50
7
1445938A00
ref: 7
CLAMP,MUFFLER CONNECTOR,R
€ 10.00
8
1446938A00
ref: 8
CLAMP,MUFFLER CONNECTOR,L
€ 10.00
9
0154706307
ref: 9
BOLT
€ 2.50
10
1431038A71H01
ref: 10
14310-38A72-H01
BODY,MUFFLER
€ 271.00
11
1434038A71H01
ref: 11
14340-38A72-H01
BODY,MUFFLER
€ 249.00
12
1477238B00
ref: 12
CLAMP,EXHAUST COUPLER
€ 6.00
13
0151706257
ref: 13
01550-06257
BOLT 6X25
€ 2.50
14
0110708307
ref: 14
01500-08307
BOLT
€ 2.50
15
0832211088
ref: 15
08322-01087
WASHER
€ 2.00
16
0916008004
ref: 16
09160-08134
WASHER
€ 2.50
17
0831626088
ref: 17
08316-20087
NUT
€ 3.00
