GEAR SHIFTING

VS800 BOULEVARD S50 2007 (K7) CALIFORNIA (E33)

Gear shifting diagram VS800 BOULEVARD S50 2007 (K7) CALIFORNIA (E33)

GEAR SHIFTING VS800 BOULEVARD S50 2007 (K7) CALIFORNIA (E33)
GEAR SHIFTING VS800 BOULEVARD S50 2007 (K7) CALIFORNIA (E33)
GEAR SHIFTING VS800 BOULEVARD S50 2007 (K7) CALIFORNIA (E33)
prices are in EUR
ref
part #
description
quantity
1
2521138A02
ref: 1
FORK,GEAR SHIFT NO.1
€ 94.00
2
2522138A01
ref: 2
FORK,GEAR SHIFT NO.2
€ 79.00
3
2541138A00
ref: 3
SHAFT,GEAR SHIFT FORK(L:115)
€ 17.00
4
2531038A03
ref: 4
CAM,GEAR SHIFT
€ 146.00
5
0422104089
ref: 5
PIN
0422104089
€ 1.50
6
2532231310
ref: 6
GEAR,GEAR SHIFT CAM DRIVEN
2532231310
€ 14.50
7
2532334201
ref: 7
PAWL,GEAR SHIFT NO.1
2532334201
€ 6.00
8
2532434201
ref: 8
PAWL,GEAR SHIFT NO.2
2532434201
€ 6.00
9
0926105003
ref: 9
PIN(5X8)
0926105003
€ 1.50
10
0944004003
ref: 10
SPRING
0944004003
€ 1.50
11
2533138A00
ref: 11
LIFTER,GEAR SHIFT POLE
2533138A00
€ 4.50
12
2534138A00
ref: 12
GUIDE,GEAR SHIFT CAM
2534138A00
€ 6.00
13
0912606011
ref: 13
SCREW(6X12)
0912606011
€ 2.00
14
0916025059
ref: 14
WASHER(25X32X3)
0916025059
€ 5.00
15
2533238A10
ref: 15
BOSS,SHIFT POLE LIFTER
2533238A10
€ 3.50
16
083161006A
ref: 16
NUT
083161006A
€ 2.50
17
0926225006
ref: 17
BEARING(25X47X8)
0926225006
€ 24.00
18
2474121A00
ref: 18
RETAINER
2474121A00
€ 2.00
19
0912506110
ref: 19
BOLT(6X12)
0912506110
€ 2.50
20
2535038A00
ref: 20
STOPPER,GEAR SHIFT CAM
2535038A00
€ 9.00
21
0944309027
ref: 21
SPRING
0944309027
€ 2.50
22
2535538A10
ref: 22
SUPPORT,CAM STOPPER ARM
€ 5.50
23
0821106141
ref: 23
WASHER
0821106141
€ 2.50
24
2538038A02
ref: 24
PLATE,GEAR SHIFT CAM
2538038A02
€ 15.00
25
2531238A00
ref: 25
PIN,SHIFT CAM DRIVEN GEAR
2531238A00
€ 4.00
26-1
0922304001
ref: 26-1
RIVET
0922304001
€ 1.50
26-2
0922304004
ref: 26-2
RIVET
0922304004
€ 2.00
27
2551038A00
ref: 27
SHAFT,GEAR SHIFT
2551038A00
€ 66.50
28
0918012068
ref: 28
SPACER(12X20X15.3)
0918012068
€ 3.00
29
0944426013
ref: 29
SPRING
0944426013
€ 3.50
30
2567101011
ref: 30
STOPPER,GEAR SHIFT ARM
2567101011
€ 3.00
31
0928512002
ref: 31
09285-12006
OIL SEAL
0928512002
€ 7.00
32
2560038A00
ref: 32
LEVER ASSY,GEAR SHIFT
2560038A00
€ 58.50
33
2565220C00
ref: 33
RUBBER,GEAR SHIFT PEDAL
2565220C00
€ 8.00
34
015000620A
ref: 34
BOLT
015000620A
€ 2.00
35
3772038A40
ref: 35
BASE,NEUTRAL SWH TERMINAL
3772038A40
€ 66.00
36
0928026005
ref: 36
O RING(D:2.4,ID:26.2)
0928026005
€ 2.50
37
021127520A
ref: 37
SCREW
021127520A
€ 3.00
38
0920905011
ref: 38
PIN(5X15.5)
0920905011
€ 2.00
39
0944004010
ref: 39
SPRING
0944004010
€ 1.50
40-1
0940406429
ref: 40-1
CLAMP(L:45)
€ 2.50
40-2
0940406433
ref: 40-2
CLAMP(L:80)
0940406433
€ 3.00
