CRANKSHAFT

VZ800Z BOULEVARD M50 2008 (K8) USA CALIFORNIA (E03 E33)

Crankshaft diagram VZ800Z BOULEVARD M50 2008 (K8) USA CALIFORNIA (E03 E33)

CRANKSHAFT VZ800Z BOULEVARD M50 2008 (K8) USA CALIFORNIA (E03 E33)
CRANKSHAFT VZ800Z BOULEVARD M50 2008 (K8) USA CALIFORNIA (E03 E33)
CRANKSHAFT VZ800Z BOULEVARD M50 2008 (K8) USA CALIFORNIA (E03 E33)
prices are in EUR
ref
part #
description
quantity
1
1200041810
ref: 1
CRANKSHAFT SET
€ 877.00
2-1
0916048001
ref: 2-1
WASHER(48.1X64X1.94)
0916048001
€ 18.50
2-10
0916048010
ref: 2-10
WASHER(48.1X64X2.16)
0916048010
€ 17.00
2-2
0916048002
ref: 2-2
WASHER(48.1X64X1.96)
0916048002
€ 17.00
2-3
0916048003
ref: 2-3
WASHER(48.1X64X1.99)
0916048003
€ 17.00
2-4
0916048004
ref: 2-4
WASHER(48.1X64X2.01)
0916048004
€ 17.00
2-5
0916048005
ref: 2-5
WASHER(48.1X64X2.04)
0916048005
€ 17.00
2-6
0916048006
ref: 2-6
WASHER(48.1X64X2.06)
0916048006
€ 17.00
2-7
0916048007
ref: 2-7
WASHER(48.1X64X2.09)
0916048007
€ 17.00
2-8
0916048008
ref: 2-8
WASHER(48.1X64X2.11)
0916048008
€ 17.00
2-9
0916048009
ref: 2-9
WASHER(48.1X64X2.14)
0916048009
€ 17.00
3-1
1222939G000A0
ref: 3-1
BEARING,CRANKSHAFT
1222939G000A0
€ 11.00
3-2
1222939G000B0
ref: 3-2
BEARING,CRANKSHAFT
1222939G000B0
€ 11.00
3-3
1222939G000C0
ref: 3-3
BEARING,CRANKSHAFT
€ 11.00
4
1265238A00
ref: 4
WASHER,CRANK THRUST
1265238A00
€ 47.00
5-1
1216045C10
ref: 5-1
CONNECTING ROD ASSY
1216045C10
€ 118.50
5-2
1216045C30
ref: 5-2
CONNECTING ROD ASSY
1216045C30
€ 118.50
6
0915909001
ref: 6
NUT
0915909001
€ 4.50
7-1
1216438E000A0
ref: 7-1
BEARING,CRANK PIN
1216438E000A0
€ 9.00
7-2
1216438E000B0
ref: 7-2
BEARING,CRANK PIN
1216438E000B0
€ 9.00
7-3
1216438E000C0
ref: 7-3
BEARING,CRANK PIN
1216438E000C0
€ 9.50
7-4
1216438E000D0
ref: 7-4
BEARING,CRANK PIN
1216438E000D0
€ 9.50
7-5
1216438E000E0
ref: 7-5
BEARING,CRANK PIN
1216438E000E0
€ 9.00
8
1211141F000F0
ref: 8
PISTON
1211141F000F0
€ 74.00
9
1214041F00
ref: 9
RING SET,PISTON
1214041F00
€ 45.50
10
1215124A00
ref: 10
PIN,PISTON
1215124A00
€ 18.50
11
0938120004
ref: 11
CIRCLIP,PISTON PIN
0938120004
€ 2.00
12
1210041F00050
ref: 12
PISTON SET,OS0
€ 114.50
13
1273138A00
ref: 13
SPROCKET,CAM CHAIN DRIVE,R
€ 34.00
14
2111138A00
ref: 14
GEAR,PRIMARY DRIVE
2111138A00
€ 99.50
15
0910312013
ref: 15
BOLT(12X28)
0910312013
€ 6.00
