Buy Suzuki VZ Parts Online


FRONT CALIPER

VZ800Z BOULEVARD M50 2009 (K9) USA CALIFORNIA (E03 E33)

Front caliper diagram VZ800Z BOULEVARD M50 2009 (K9) USA CALIFORNIA (E03 E33)

FRONT CALIPER VZ800Z BOULEVARD M50 2009 (K9) USA CALIFORNIA (E03 E33)
FRONT CALIPER VZ800Z BOULEVARD M50 2009 (K9) USA CALIFORNIA (E03 E33)
FRONT CALIPER VZ800Z BOULEVARD M50 2009 (K9) USA CALIFORNIA (E03 E33)
prices are in EUR
ref
part #
description
quantity
1
5910033DB0999
ref: 1
CALIPER ASSY,FR
€ 531.00
2
5930120880
ref: 2
PISTON SET
5930120880
€ 44.50
3
5930033841
ref: 3
SEAL SET,PISTON
5930033841
€ 26.50
4
5911533D00
ref: 4
SPRING,PAD,R
5911533D00
€ 12.00
5
5911244B00
ref: 5
BOOT,AXLE
5911244B00
€ 8.00
6
5914144B01
ref: 6
PIN,PAD
5914144B01
€ 8.00
7
5931336500
ref: 7
INSULATOR,AXLE
5931336500
€ 5.50
8
6914245000
ref: 8
CLIP,PAD PIN
6914245000
€ 4.50
9
5915033D01
ref: 9
CARRIER,CALIPER,R
5915033D01
€ 70.00
10
5911633D00
ref: 10
GUIDE,PAD
5911633D00
€ 6.50
11
5912118410
ref: 11
BLEEDER
5912118410
€ 8.00
12
5515666310
ref: 12
CAP,BLEEDER PLUG
5515666310
€ 6.00
13
5910233820
ref: 13
PAD SET (NAS)
5910233820
€ 49.50
14
0910310379
ref: 14
BOLT(10X30)
0910310379
€ 4.00
