Buy Suzuki VZR Parts Online


HOLDER

VZR1800N BOULEVARD M109R 2008 (K8) CALIFORNIA (E33)

Holder diagram VZR1800N BOULEVARD M109R 2008 (K8) CALIFORNIA (E33)

HOLDER VZR1800N BOULEVARD M109R 2008 (K8) CALIFORNIA (E33)
HOLDER VZR1800N BOULEVARD M109R 2008 (K8) CALIFORNIA (E33)
HOLDER VZR1800N BOULEVARD M109R 2008 (K8) CALIFORNIA (E33)
prices are in EUR
ref
part #
description
quantity
1
4154148G00
ref: 1
HOLDER,BATTERY
4154148G00
€ 25.00
2
4711516G00
ref: 2
CUSHION,SEAT TAIL COVER CTR
4711516G00
€ 3.00
3
0913606105
ref: 3
SCREW(6X20)
0913606105
€ 2.00
4
0918006289
ref: 4
SPACER(6.5X10X11.5)
0918006289
€ 2.50
5
4155048G00
ref: 5
HOLDER,ELECTRIC PARTS
€ 17.00
6-1
0910306100
ref: 6-1
BOLT(6X8)
0910306100
€ 2.00
6-2
021620608A
ref: 6-2
SCREW
021620608A
€ 1.50
7-1
015500610A
ref: 7-1
BOLT
015500610A
€ 2.00
7-2
021620610A
ref: 7-2
SCREW
€ 2.00
8-1
015500616A
ref: 8-1
BOLT
015500616A
€ 2.50
8-2
021620616A
ref: 8-2
02162-0616B
SCREW
€ 1.50
9
4156048G00
ref: 9
BRACKET,RELAY
€ 18.00
10
4743248G00
ref: 10
LID,BATTERY HOLDER
4743248G00
€ 12.00
11
0940908329
ref: 11
GROMMET
0940908329
€ 2.50
12
0940908330
ref: 12
PLUNGER
0940908330
€ 2.50
13
0980021055
ref: 13
TOOL ASSY
0980021055
€ 6.00
14
6311535G10
ref: 14
CUSHION,SEAT RAIL
€ 3.50
