CRANKSHAFT (MODEL K1/K2/K3/K4)

DR-Z400E 2004 (K4) USA (E03) DRZ400E DR Z400E

Crankshaft (model k1/k2/k3/k4) diagram DR-Z400E 2004 (K4) USA (E03) DRZ400E DR Z400E

CRANKSHAFT (MODEL K1/K2/K3/K4) DR-Z400E 2004 (K4) USA (E03) DRZ400E DR Z400E
CRANKSHAFT (MODEL K1/K2/K3/K4) DR-Z400E 2004 (K4) USA (E03) DRZ400E DR Z400E
CRANKSHAFT (MODEL K1/K2/K3/K4) DR-Z400E 2004 (K4) USA (E03) DRZ400E DR Z400E
prices are in EUR
ref
part #
description
quantity
1-1
1220029F01
ref: 1-1
CRANKSHAFT ASSY
€ 704.50
1-2
1220029F30
ref: 1-2
CRANKSHAFT ASSY
€ 524.50
1-3
1220029F21
ref: 1-3
CRANKSHAFT ASSY
€ 770.00
1-4
1220029F40
ref: 1-4
12200-29F41
CRANKSHAFT ASSY (DR-Z400EK4E33)
€ 547.00
1-5
1220029F40
ref: 1-5
12200-29F41
CRANKSHAFT ASSY (DR-Z400EK4E33)
€ 547.00
2
1216029F010B0
ref: 2
12160-29F02-0B0
CONNECTING ROD COMP
€ 106.50
3-1
1221029F00
ref: 3-1
12210-29F01
PIN COMP,CRANK
€ 48.00
3-2
1221029F10
ref: 3-2
12210-29F11
PIN COMP,CRANK
1221029F10
€ 48.00
4
09263350370B0
ref: 4
BEARING(35X43X22)
€ 58.50
5-1
1222129F20
ref: 5-1
12221-29F30
CRANKSHAFT,RIGHT
€ 177.00
5-2
1222129F30
ref: 5-2
CRANKSHAFT, RH
€ 177.00
6-1
1226129F00
ref: 6-1
CRANKSHAFT,L
1226129F00
€ 245.00
6-2
1226129F30
ref: 6-2
CRANKSHAFT,L
€ 186.00
6-3
1226129F10
ref: 6-3
12261-07G00
CRANKSHAFT,LEFT
€ 200.50
6-4
1226107G00
ref: 6-4
CRANKSHAFT,L
€ 200.50
7
1266129F00
ref: 7
GEAR,CRANK BALANCER DRIVE
1266129F00
€ 85.50
8
0926105005
ref: 8
PIN(5X8)
0926105005
€ 1.50
9
0926230100
ref: 9
BEARING(30X72X18)
0926230100
€ 61.50
10
0928214003
ref: 10
SEAL,OIL(14X24X6)
0928214003
€ 8.00
11
2474218A00
ref: 11
RETAINER,BEARING
2474218A00
€ 2.00
12
0211206123
ref: 12
02112-0612A
SCREW
0211206123
€ 1.50
13-1
1273129F00
ref: 13-1
SPROCKET,CAM CHAIN DRIVE
1273129F00
€ 77.00
13-2
1273129F10
ref: 13-2
SPROCKET,CAM CHAIN DRIVE
1273129F10
€ 37.00
14-1
2111129F00
ref: 14-1
GEAR,PRIMARY DRIVE
€ 75.50
14-2
2111129F10
ref: 14-2
GEAR,PRIMARY DRIVE
€ 49.00
15
0914018012
ref: 15
NUT
0914018012
€ 8.00
16
0916418007
ref: 16
09164-18001
WASHER
0916418007
€ 3.00
17
0942105002
ref: 17
KEY
0942105002
€ 4.50
18
1211129F000F0
ref: 18
PISTON
1211129F000F0
€ 99.00
19
1214029F00
ref: 19
RING SET,PISTON
1214029F00
€ 57.50
20
1215124F10
ref: 20
PIN,PISTON
1215124F10
€ 15.50
21
0938120004
ref: 21
CIRCLIP,PISTON PIN
0938120004
€ 2.00
