CLUTCH

ref

part #

description

quantity

600

KK600A1000
ref: 600

BALL-STEEL,5/16

€ 1.50

13087

K130870007
ref: 13087
K1308-70017

HUB-CLUTCH

€ 97.50

13088

K130880005
ref: 13088

PLATE-FRICTION

€ 13.50

13088A

K130880006
ref: 13088A

PLATE-FRICTION

€ 13.50

13089

KK13089013
ref: 13089

PLATE-CLUTCH,T

€ 11.00

13095

K130950018
ref: 13095
K1309-50049

HOUSING,CLUTCH

€ 379.50

13102

K131020002
ref: 13102
K1310-20020

RELEASE-COMP-C

€ 35.00

13116

K131160003
ref: 13116

ROD-PUSH

€ 19.00

13187

K131871089
ref: 13187

PLATE-CLUTCH OPERATING

€ 42.00

13280

K132801266
ref: 13280
K1328-00339

HOLDER

€ 28.50

14044

K140440002
ref: 14044

HOLDER-CABLE,CLUTCH

€ 8.00

92036

KK92036007
ref: 92036

RING-SNAP,PISTON PIN

€ 3.50

92046

K920460002
ref: 92046

BEARING-NEEDLE

€ 19.50

92046A

K920461190
ref: 92046A

BEARING-NEEDLE,FNTA-1326

€ 11.50

92046B

K920460016
ref: 92046B

BEARING,NEEDLE

€ 31.00

92139

K921390014
ref: 92139

BUSHING

€ 24.00

92145

K921451487
ref: 92145

SPRING

€ 5.00

92153

K921531123
ref: 92153

BOLT,6.25

€ 1.50

92200

K922000027
ref: 92200

WASHER,21.6X38X2.5

€ 5.00

92200A

K922000045
ref: 92200A

WASHER,13.4X25X1.0

€ 2.50

92200B

K922000098
ref: 92200B

WASHER

€ 1.00

92200C

K922001548
ref: 92200C

WASHER,T=1.5

€ 2.50

92210

K922101207
ref: 92210

NUT,16MM

€ 14.00
