METER VISOR

DR600RU 1988 (J)

Meter visor diagram DR600RU 1988 (J)

METER VISOR DR600RU 1988 (J)

METER VISOR DR600RU 1988 (J)

prices are in EUR

ref

part #

description

quantity

1

9461114A00
ref: 1
MODEL G

VISOR, METER

€ 143.00

2

9463114A00
ref: 2
MODEL G

MOLDING (L:545)

€ 15.00

3

0214205104
ref: 3
MODEL G

SCREW 5X10

€ 2.50

4

0932005008
ref: 4
MODEL G

CUSHION

€ 5.00

5

0832221055
ref: 5
MODEL G

WASHER,5MM

€ 2.50

6

0831311055
ref: 6
MODEL G

NUT

€ 2.00

7

9461115A00
ref: 7
MODEL H/J/K

VISOR, METER

€ 94.00

8-1

9463115A00
ref: 8-1
MODEL H/J/K

MOLDING

€ 15.00

8-2

9463115A10
ref: 8-2
MODEL H/J/K E17

MOLDING

€ 14.00

9

0214205104
ref: 9
MODEL H/J/K

SCREW 5X10

€ 2.50

10

0932005008
ref: 10
MODEL H/J/K

CUSHION

€ 5.00

11

0832221055
ref: 11
MODEL H/J/K

WASHER,5MM

€ 2.50

12

0831311055
ref: 12
MODEL H/J/K

NUT

€ 2.00
