Buy Suzuki DR Parts Online


OIL PUMP

DR600RU 1988 (J)

Oil pump diagram DR600RU 1988 (J)

OIL PUMP DR600RU 1988 (J)
OIL PUMP DR600RU 1988 (J)
OIL PUMP DR600RU 1988 (J)
prices are in EUR
ref
part #
description
quantity
1
1640037400
ref: 1
PUMP ASSY,ENGINE OIL
1640037400
€ 153.00
2
1633114A00
ref: 2
GEAR,OIL PUMP DRIVEN
€ 23.50
3
0926104009
ref: 3
PIN(4X15.8)
0926104009
€ 1.50
4
0822110185
ref: 4
SHIM
0822110185
€ 2.00
5
0833131109
ref: 5
CIRCLIP
0833131109
€ 2.00
6
0211206258
ref: 6
SCREW
€ 2.00
7
1652014A00
ref: 7
STRAINER,ENGINE OIL
1652014A00
€ 8.50
8
0211205126
ref: 8
SCREW 5X12
€ 1.50
9
0832121056
ref: 9
LOCK WASHER
0832121056
€ 3.00
10
0832221056
ref: 10
WASHER
€ 2.50
11
1652337401
ref: 11
CAP,OIL STRAINER
1652337401
€ 56.00
12
0928082001
ref: 12
O RING(D:2.4,ID:85)
0928082001
€ 6.50
13
0151706208
ref: 13
BOLT,REAR
€ 2.50
14
0924714001
ref: 14
PLUG
0924714001
€ 5.00
15
0916814004
ref: 15
GASKET(14X19.2X2) (NAS)
0916814004
€ 2.50
16
1651037440
ref: 16
FILTER,ENGINE OIL
1651037440
€ 7.50
17
0928016005
ref: 17
O RING(D:2.4,ID:15.8)
0928016005
€ 1.50
18
1651214A01
ref: 18
CAP,OIL FILTER
1651214A01
€ 26.00
19
0928072001
ref: 19
O RING(D:2.4,ID:73)
0928072001
€ 5.00
20
0944021004
ref: 20
SPRING
0944021004
€ 13.00
21
0142106128
ref: 21
STUD 6X12
0142106128
€ 1.50
22
0831311065
ref: 22
NUT 6MM
0831311065
€ 2.00
