FRONT DAMPER
DR650SE 2012 (L2) USA (E03)
Front damper diagram DR650SE 2012 (L2) USA (E03)
FRONT DAMPER DR650SE 2012 (L2) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
5110332E00
ref: 1
DAMPER ASSY,FR FORK,R
€ 779.00
2
5113032E00
ref: 2
TUBE,OUTER,R
€ 415.00
3
5119506C00
ref: 3
PIECE,OIL LOCK
€ 13.00
4
5116740C00
ref: 4
METAL,SLIDE
€ 13.50
5
5115814200
ref: 5
WASHER
€ 4.00
6
5115314330
ref: 6
SEAL,OIL
€ 11.00
7
5117314330
ref: 7
SEAL,DUST
€ 9.50
8
5115614200
ref: 8
RING,STOPPER
€ 4.50
9
5111032E00
ref: 9
TUBE,INNER
€ 383.50
10
5112140C00
ref: 10
PISTON
€ 11.50
11
5119032E00
ref: 11
CYLINDER
€ 114.50
12
5117714330
ref: 12
SPRING,REBOUND
€ 5.50
13
5119631D00
ref: 13
RING,PISTON
€ 6.00
14
5117132E00
ref: 14
SPRING
€ 66.00
15
5117232E00
ref: 15
WASHER
€ 4.00
16
5117632E00
ref: 16
SPACER
€ 25.00
17
5111714200
ref: 17
O RING
€ 2.00
18
5135131D00
ref: 18
CAP,FORK
€ 32.50
19
5114716510
ref: 19
BOLT,FORK CYLINDER(10X25)
€ 3.50
20
5114841310
ref: 20
GASKET (NAS)
€ 2.50
21
5113232E00
ref: 21
HOLDER,AXLE,R
€ 31.50
22
0831610067
ref: 22
NUT
€ 2.00
23
5110432E00
ref: 23
DAMPER ASSY,FR FORK,L
€ 779.00
24
5114032E00
ref: 24
TUBE,OUTER,L
€ 448.50
25
5119506C00
ref: 25
PIECE,OIL LOCK
€ 13.00
26
5116740C00
ref: 26
METAL,SLIDE
€ 13.50
27
5115814200
ref: 27
WASHER
€ 4.00
28
5115314330
ref: 28
SEAL,OIL
€ 11.00
29
5117314330
ref: 29
SEAL,DUST
€ 9.50
30
5115614200
ref: 30
RING,STOPPER
€ 4.50
31
5111032E00
ref: 31
TUBE,INNER
€ 383.50
32
5112140C00
ref: 32
PISTON
€ 11.50
33
5119032E00
ref: 33
CYLINDER
€ 114.50
34
5117714330
ref: 34
SPRING,REBOUND
€ 5.50
35
5119631D00
ref: 35
RING,PISTON
€ 6.00
36
5117132E00
ref: 36
SPRING
€ 66.00
37
5117232E00
ref: 37
WASHER
€ 4.00
38
5117632E00
ref: 38
SPACER
€ 25.00
39
5111714200
ref: 39
O RING
€ 2.00
40
5135131D00
ref: 40
CAP,FORK
€ 32.50
41
5114716510
ref: 41
BOLT,FORK CYLINDER(10X25)
€ 3.50
42
5114841310
ref: 42
GASKET (NAS)
€ 2.50
43
5120332E00
ref: 43
GUIDE,BOOT
€ 14.00
44
0713005207
ref: 44
BOLT
€ 2.00
45
5157600B00
ref: 45
BAND,BOOT LWR
€ 6.50
46
5157132E00019
ref: 46
BOOT, BLACK
€ 45.50
47
5157532E00
ref: 47
BAND,BOOT
€ 8.00
