prices are in EUR
ref
part #
description
quantity
1-2
SEAT, FLAT TYPE (WITH BAND)
2-2
SEAT, STEP TYPE (WITH BAND)
11-1
MOLDING,SEAT
11-6
PLATE, SEAT LOWER
12-2
NUT
13
PIN
14
PIN
15
CUSHION
16
CUSHION
29
COVER ASSY, SEAT TAIL
30
TAPE SET
34
CLIP,SEAT TAIL COVER M
35
WASHER
36
NUT 6MM
37
STRIKER,SEAT LOCK
38
NUT
39
LOCK WASHER
40
WASHER
41
WASHER (6.5X20X1.2)
42
REFLEX REFLECTOR,RR
44
NUT
45
LOCK ASSY,SEAT
47
LOCK WASHER
48
SPRING,HELMET HOLDER
49
SCREW
50
HOLDER,TOOL
51
WASHER
52
NUT
53
BAND
55
GAUGE ASSEMBLY,AIR PRESSURE
57
BOLT
58
WASHER
