CYLINDER

GS450S 1988 (J) (E04 E22 E34 E77)

Cylinder diagram GS450S 1988 (J) (E04 E22 E34 E77)

CYLINDER GS450S 1988 (J) (E04 E22 E34 E77)

CYLINDER GS450S 1988 (J) (E04 E22 E34 E77)

prices are in EUR

ref

part #

description

quantity

1

1121044110
ref: 1

CYLINDER

€ 522.00

2

0910810071
ref: 2

STUD

€ 9.00

3

0421111189
ref: 3

PIN

€ 2.00

4

1124144100
ref: 4

GASKET,CYLINDER (MCA)

€ 12.50

5

0928074002
ref: 5

O RING(D:2,ID:74)

€ 6.00
