SECOND AIR (E18,E39)

ref

part #

description

quantity

1

1870017C03
ref: 1

CLEANER ASSEMBLY,SECOND AIR

€ 38.00

2

0155006123
ref: 2

BOLT

€ 2.50

3

1875001D00
ref: 3

BRACKET,2ND AIR CLEANER

€ 0.00

4

1876001D00
ref: 4

BRACKET,2ND AIR CLNR SUPPORT

€ 0.00

5

1842001810
ref: 5

HOSE SET, 2ND AIR

€ 0.00

6

0940125403
ref: 6

CLIP

€ 3.00

7

1851006B00
ref: 7

VALVE ASSY,2ND AIR SWITCHING

€ 100.50

8

1848339A00
ref: 8

CAP,SWITCHING VALVE

€ 7.50

9

1852101D00
ref: 9

BRACKET, SWITCHING VALVE

€ 0.00

10

0155006163
ref: 10

BOLT

€ 2.50

11

1848701D00
ref: 11

CUSHION,2ND AIR VALVE

€ 10.00

12

0935545855600
ref: 12
L:600->200

HOSE(4.5X8.5X600)

€ 14.00

13

0940121403
ref: 13
MODEL V

CLIP

€ 3.00

13

0940120405
ref: 13
MODEL W/X

CLIP

€ 3.00

14

1845048B00
ref: 14

VALVE ASSY,2ND AIR REED

€ 125.50

15

1872101D00
ref: 15

BRACKET, REED VALVE

€ 0.00

16

0155006163
ref: 16

BOLT

€ 2.50

17

1844501D00
ref: 17

HOSE,2ND AIR REED VALVE,R

€ 0.00

18

1844501D00
ref: 18

HOSE,2ND AIR REED VALVE,R

€ 0.00

19

0940113413
ref: 19
MODEL V

CLIP

€ 2.50

19

0940113417
ref: 19
MODEL W/X

CLIP

€ 2.50

20

1842001D01
ref: 20

PIPE,2ND AIR,R

€ 53.00

21

1843001D01
ref: 21

PIPE,2ND AIR,L

€ 40.00

22

1844145C00
ref: 22

GASKET,SECOND AIR PIPE (N (NAS)

€ 6.00

23

0142106163
ref: 23

STUD BOLT

€ 2.00

24

0831610063
ref: 24

NUT

€ 2.50

all assemblies
