CRANKCASE
GS500F 2005 (K5) USA (E03)
Crankcase diagram GS500F 2005 (K5) USA (E03)
CRANKCASE GS500F 2005 (K5) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1-2
1130101810
ref: 1-2
11301-01811
CRANKCASE SET
€ 1,070.50
2
0920613004
ref: 2
PIN(10.4X13X22)
€ 3.00
3
0920611007
ref: 3
PIN(8.4X11X20)
€ 1.50
4
0713008703
ref: 4
07130-0870B
BOLT
€ 4.00
5
0910308182
ref: 5
BOLT(8X125)
€ 4.50
6
0910308134
ref: 6
BOLT(8X110)
€ 3.00
7
0910308230
ref: 7
BOLT(8X100)
€ 3.00
8
0155008653
ref: 8
01550-0865A
BOLT
€ 3.00
9
0155008453
ref: 9
01550-0845A
BOLT
€ 3.00
10
0910306033
ref: 10
BOLT(6X125)
€ 3.50
11
0910306067
ref: 11
BOLT(6X105)
€ 3.50
12
0155006903
ref: 12
01550-0690B
BOLT (6X90)
€ 3.50
13
0155006703
ref: 13
01550-0670B
BOLT
€ 2.50
14
0155006653
ref: 14
01550-0665A
BOLT
€ 2.50
15
0155006507
ref: 15
BOLT
€ 2.00
16
0155006453
ref: 16
01550-0645A
BOLT (6X45)
€ 2.50
17
0916808016
ref: 17
GASKET(8.2X14X1) (NAS)
€ 1.00
18
0949322010
ref: 18
JET,AIR
€ 12.00
19
0949332002
ref: 19
JET
€ 11.50
20
0949324008
ref: 20
JET
€ 16.00
21
0928003003
ref: 21
O RING(D:1.05,ID:3.1)
€ 2.50
22
0910310137
ref: 22
BOLT(10X255)
€ 10.00
23
0910310154
ref: 23
BOLT(10X245)
€ 16.00
24
0910310127
ref: 24
BOLT(10X170)
€ 16.00
25
0910310278
ref: 25
BOLT(10X160)
€ 9.50
26
0915910078
ref: 26
NUT
€ 4.50
27
1161101D10
ref: 27
SPACER,ENG MTG(L:16.8)
€ 8.00
28
1161045410
ref: 28
SPACER,ENGINE MOUNT(L:65)
€ 11.50
29
1152144100
ref: 29
PLATE,OIL SEPARATOR
€ 3.00
30
0912506110
ref: 30
BOLT(6X12)
€ 2.50
31
1153246E00
ref: 31
JET,OIL PAN GALLERY
€ 7.50
