REAR WHEEL

GS500F 2005 (K5) USA (E03)

Rear wheel diagram GS500F 2005 (K5) USA (E03)

REAR WHEEL GS500F 2005 (K5) USA (E03)
REAR WHEEL GS500F 2005 (K5) USA (E03)
REAR WHEEL GS500F 2005 (K5) USA (E03)
prices are in EUR
ref
part #
description
quantity
1
6411134C01291
ref: 1
WHEEL,RR(MT3.50X17)
€ 723.50
2
6921101DA0
ref: 2
DISC REAR BRAK
6921101DA0
€ 212.50
3
0910608131
ref: 3
BOLT(8X30)
0910608131
€ 3.50
4
6972101DA0
ref: 4
BRACKET,CALIPE
6972101DA0
€ 16.50
5
64740C19C00J000
ref: 5
64740-19C00
SPACER, REAR AXLE RH
€ 6.50
6
64611C01D00J000
ref: 6
64611-01D00
DRUM, REAR SPROCKET
€ 119.50
7
6465127A01
ref: 7
ABSORBER,RR HUB SHOCK
6465127A01
€ 6.00
8
6471101D20
ref: 8
AXLE,RR
€ 55.50
9
64733C01D00J000
ref: 9
RETAINER, DRUM
€ 17.50
10
64751C19C00J000
ref: 10
64751-19C00
SPACER, REAR AXLE LH
€ 12.50
11
0916017047
ref: 11
WASHER(17X30X3)
0916017047
€ 5.00
12
0831440163
ref: 12
08314-4016A
NUT
0831440163
€ 4.50
13
0918017067
ref: 13
SPACER(17.5X25X88)
0918017067
€ 13.50
14
0814363037
ref: 14
BEARING
0814363037
€ 23.00
15
0926225073
ref: 15
BEARING(25X62X17)
0926225073
€ 21.50
16
0928535001
ref: 16
SEAL,OIL(35X62X8)
0928535001
€ 9.00
17
64511C01D04J000
ref: 17
64511-01D04
SPROCKET, REAR (NT:39)
64511C01D04J000
€ 31.00
18
0911910059
ref: 18
BOLT
0911910059
€ 3.50
19
0831931108
ref: 19
NUT
0831931108
€ 3.00
20
61410C01D00J000
ref: 20
61410-01D00
ADJUSTER, CHAIN
€ 18.00
21
61421C01D00J000
ref: 21
61421-01D00
PLATE, GUIDE
€ 7.50
22
0831931088
ref: 22
08319-3108A
NUT
€ 2.50
23
64712C19C01J00
ref: 23
64712-19C01
WASHER,CHAIN A
€ 5.50
24
64712C01D00J000
ref: 24
64712-01D00
WASHER, CHAIN ADJUSTER LH
€ 7.00
25
6511001D10
ref: 25
TIRE, REAR (130/70-17M/C 62H)
€ 137.50
26
4313007E00
ref: 26
VALVE
4313007E00
€ 3.00
27-1
5541100A00
ref: 27-1
BALANCER,WHEEL (10G)
€ 6.50
27-2
5541200A01
ref: 27-2
55412-17G00
BALANCER,WHEEL (20G)
€ 7.00
27-3
5511117G00
ref: 27-3
55411-17G00
BALANCER,WHEEL(10G)
€ 6.50
27-4
5511217G00
ref: 27-4
55412-17G00
BALANCER,WHEEL(20G)
€ 7.00
27-5
5511317G00
ref: 27-5
55413-17G00
BALANCER,WHEEL(30G)
€ 7.50
28
0411140308
ref: 28
04111-4030A
PIN,COTTER
0411140308
€ 1.50
