FRONT CALIPERS

GS550ES 1983 (D) USA (E03)

Front calipers diagram GS550ES 1983 (D) USA (E03)

FRONT CALIPERS GS550ES 1983 (D) USA (E03)

FRONT CALIPERS GS550ES 1983 (D) USA (E03)

prices are in EUR

ref

part #

description

quantity



5910033410
ref:

CALIPER ASSEMBLY,RIGHT

€ 372.00



5930033410
ref:

CALIPER ASSEMBLY,LEFT

€ 380.00

1

6910016810
ref: 1
69100-27821

PISTON SET

€ 192.50

2

5913016700
ref: 2
59100-16820

PAD (MCA)

€ 43.00

3

5910718410
ref: 3
69107-05CF0

SEAL,PISTON

€ 17.00

4

5910816700
ref: 4

BOOT

€ 16.50

5

6910734200
ref: 5

SEAL,JOINT

€ 12.00

6

6914516700
ref: 6
59145-05C50

BOLT

€ 9.50

7

6914145000
ref: 7

PIN,PAD

€ 6.50

8

6914245000
ref: 8

CLIP,PAD PIN

€ 4.50

9

5914316700
ref: 9

SPRING

€ 7.50

10

5915116700
ref: 10
59151-16701

COVER,CALIPER

€ 13.50

11

5912118410
ref: 11

BLEEDER

€ 8.00

12

5912218410
ref: 12
55156-66310

CAP,BREATHER

€ 6.00

13

5937133420
ref: 13

SHIM

€ 14.00

14

0910310038
ref: 14
09103-10038-XC0

BOLT 10X37

€ 3.00
