FRAME

GS850G 1984 (E) (E01 E02 E04 E06 E22 E24 E25)

Frame diagram GS850G 1984 (E) (E01 E02 E04 E06 E22 E24 E25)

prices are in EUR

ref

part #

description

quantity

1-1

4110049401019
ref: 1-1

FRAME

€ 1,399.50

1-2

4110049411019
ref: 1-2
E22

FRAME (BLACK)

€ 0.00

4191045101019
ref: 2

PLATE,ENGINE MOUNTING

€ 8.50

0110708655
ref: 3

BOLT

€ 3.00

0832121084
ref: 4

WASHER,LOCK,8.

€ 2.50

4199345000019
ref: 5

PLATE,ENGINE MOUNTING

€ 5.50

0110708165
ref: 6

BOLT

€ 2.00

0832121084
ref: 7

WASHER,LOCK,8.

€ 2.50

4197045100019
ref: 8

PLATE,ENGINE MOUNTING

€ 0.00

4198045350019
ref: 9

PLATE,ENGINE MOUNTING

€ 0.00

0110708405
ref: 10

BOLT 8X40

€ 3.00

0832121084
ref: 11

WASHER,LOCK,8.

€ 2.50

4161149401
ref: 12

GRIP,FRAME HANDLE

€ 26.50

0110708168
ref: 13

BOLT

€ 2.00

0832121088
ref: 14

LOCK WASHER

€ 2.00

0832211088
ref: 15

WASHER

€ 2.00

4155145110
ref: 16

HOLDER,TOOL

€ 29.00

0980000251
ref: 17

TOOL SET

€ 43.00
