CYLINDER HEAD
GSF1200Z BANDIT 2005 (K5) USA (E03)
Cylinder head diagram GSF1200Z BANDIT 2005 (K5) USA (E03)
CYLINDER HEAD GSF1200Z BANDIT 2005 (K5) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
1110027E60
ref: 1
HEAD ASSY,CYLINDER
€ 1,855.50
2
0938110004
ref: 2
RING,SNAP
€ 1.50
3
0910306026
ref: 3
BOLT(6X39)
€ 2.00
4
0920608001
ref: 4
PIN(6.2X8X11)
€ 2.00
5
1111606B70
ref: 5
GUIDE,VALVE
€ 43.00
6
1114132F01
ref: 6
GASKET,CYLINDER HEAD (NAS)
€ 91.50
7
1114332F00
ref: 7
O RING,HEAD GASKET
€ 6.00
8
0920911007
ref: 8
PIN
€ 16.00
9
0155006303
ref: 9
01550-0630A
BOLT
€ 2.50
10
0915910069
ref: 10
NUT
€ 5.00
11
0831610103
ref: 11
08316-1010B
NUT
€ 2.00
12
0916810031
ref: 12
GASKET(10.2X20X2).3 (NAS)
€ 2.00
13
0916010060
ref: 13
09160-10039
WASHER (10.5X22X2.3)
€ 2.50
14
1113840C10
ref: 14
PLATE,HEAD REINFORCEMENT
€ 27.00
15
1113127A00
ref: 15
PIPE,OIL NO.1
€ 6.00
16
1113327A00
ref: 16
PIPE,OIL NO.3
€ 7.00
17
1113527A02
ref: 17
PLATE,OIL PIPE,R
€ 4.00
18
1113627A02
ref: 18
PLATE,OIL PIPE,L
€ 4.00
19
0155006123
ref: 19
01550-0612A
BOLT
€ 2.50
20-1
0948200389
ref: 20-1
PLUG,SPARK(JR9B)
€ 8.00
20-2
0948200391
ref: 20-2
PLUG,SPARK(JR10B)
€ 9.00
21
1310132F00
ref: 21
PIPE ASSY,INTAKE,L
€ 44.00
22
1310332F00
ref: 22
PIPE ASSY,INTAKE,R
€ 44.00
23
0928042003
ref: 23
O RING(D:2.4,ID:41.7)
€ 8.50
24
0940252208
ref: 24
CLAMP
€ 5.50
25
0712006163
ref: 25
07120-0616B
BOLT MAGNETO S
€ 2.50
26-1
0924814010
ref: 26-1
PLUG
€ 5.00
26-2
0924814012
ref: 26-2
PLUG,14X12
€ 5.00
27
0916814002
ref: 27
09168-14004
GASKET(13.8X18.8X4.8) (NAS)
€ 2.50
