SEAT
GSF1200Z BANDIT 2005 (K5) USA (E03)
Seat diagram GSF1200Z BANDIT 2005 (K5) USA (E03)
SEAT GSF1200Z BANDIT 2005 (K5) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
4510031F11BH4
ref: 1
SEAT ASSY
€ 383.50
2
4514931300
ref: 2
CUSHION,SEAT(40X20X15)
€ 2.00
3
0932110011
ref: 3
CUSHION
€ 3.00
4
4521331300
ref: 4
CUSHION
€ 1.50
5
4514905350
ref: 5
CUSHION
€ 2.00
6
4522020A01
ref: 6
45220-47H00
BRACKET,SEAT SUPPORT,RIGHT
€ 79.50
7
0212206303
ref: 7
02122-0630B
SCREW
€ 2.00
8
9570010834
ref: 8
95700-10835
LOCK SET,SEAT & HELMET
€ 99.50
9
0913906092
ref: 9
SCREW(6X14)
€ 3.50
10
4528020A00
ref: 10
CABLE,TANK LOCK
€ 16.00
11
0940714403
ref: 11
CLAMP(L:125)
€ 2.50
