Buy Suzuki GSX Parts Online


FRONT BRAKE HOSE

GSX1300RZ HAYABUSA 2007 (K7) USA (E03)

Front brake hose diagram GSX1300RZ HAYABUSA 2007 (K7) USA (E03)

FRONT BRAKE HOSE GSX1300RZ HAYABUSA 2007 (K7) USA (E03)
FRONT BRAKE HOSE GSX1300RZ HAYABUSA 2007 (K7) USA (E03)
FRONT BRAKE HOSE GSX1300RZ HAYABUSA 2007 (K7) USA (E03)
prices are in EUR
ref
part #
description
quantity
1
5960024F00
ref: 1
CYLINDER ASSY,FR MASTER
5960024F00
€ 271.00
2
5960045860
ref: 2
PISTON & CUP SET
5960045860
€ 44.00
3
5966644300
ref: 3
BOOT
5966644300
€ 6.00
4
5966448B00
ref: 4
PROTECTOR
5966448B00
€ 8.00
5
5966749460
ref: 5
5966749460
6
5966841C00
ref: 6
PLATE,DIAPHRAGM
5966841C00
€ 8.00
7
5966941C00
ref: 7
CAP
5966941C00
€ 30.00
8
6968949300
ref: 8
SCREW
6968949300
€ 1.50
9
5967136500
ref: 9
HOLDER
5967136500
€ 10.00
10
5967502FA0
ref: 10
BOLT(6X22)
5967502FA0
€ 3.00
11
0936010042
ref: 11
09360-10062
BOLT UNION
0936010042
€ 5.00
12
0936010042
ref: 12
09360-10062
BOLT UNION
0936010042
€ 5.00
13
0936010044
ref: 13
09360-10064
BOLT UNION
€ 5.00
14
0916110009
ref: 14
WASHER(10X15X1.5)
0916110009
€ 2.00
15
5948024F01
ref: 15
59480-24F02
HOSE,FRONT BRAKE NO.1
5948024F01
€ 99.50
16
5924024F01
ref: 16
59240-24F02
HOSE,FRONT BRAKE NO.2
€ 108.50
17
5926638D00
ref: 17
CLAMP,FR BRAKE HOSE UPR
5926638D00
€ 13.00
18
5926833E01
ref: 18
GUIDE,FR BRAKE HOSE NO.1
5926833E01
€ 12.00
19-1
0155006163
ref: 19-1
01550-0616A
BOLT
0155006163
€ 2.50
19-2
015500616A
ref: 19-2
BOLT
015500616A
€ 2.50
20
0940314304
ref: 20
CLAMP
0940314304
€ 3.00
