HANDLE SWITCH

GSX1300RZ HAYABUSA 2007 (K7) USA (E03)

Handle switch diagram GSX1300RZ HAYABUSA 2007 (K7) USA (E03)

HANDLE SWITCH GSX1300RZ HAYABUSA 2007 (K7) USA (E03)

HANDLE SWITCH GSX1300RZ HAYABUSA 2007 (K7) USA (E03)

prices are in EUR

ref

part #

description

quantity

1-1

3720033E51
ref: 1-1

SWITCH ASSY,HANDLE,R

€ 193.50

1-2

3720033E60
ref: 1-2

SWITCH ASSY,HANDLE,R

€ 174.50

2

0211205305
ref: 2
02112-0530B

SCREW

€ 1.50

3

0211205505
ref: 3
02112-0550B

SCREW

€ 2.00

4

3740024F10
ref: 4

SWITCH ASSY,HANDLE,L

€ 228.00

5

0211205253
ref: 5
02112-0525A

SCREW

€ 1.50

6

0211205455
ref: 6
02112-0545B

SCREW, 5X45

€ 4.00

7

021120510B
ref: 7

SCREW

€ 2.00
