STAND

GSX1300RZ HAYABUSA 2007 (K7) USA (E03)

Stand diagram GSX1300RZ HAYABUSA 2007 (K7) USA (E03)

STAND GSX1300RZ HAYABUSA 2007 (K7) USA (E03)

STAND GSX1300RZ HAYABUSA 2007 (K7) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

4231024F00
ref: 1

STAND,PROP

€ 109.50

2

0911110059
ref: 2

BOLT(10X21)

€ 7.00

3

0915910103
ref: 3

NUT

€ 3.00

4

0944314068
ref: 4

SPRING

€ 5.00

5

0944319015
ref: 5

SPRING

€ 5.00

6

4233024F00
ref: 6
42330-24F01

BRACKET COMP,PROP STAND

€ 104.00

7

0910012077
ref: 7

BOLT(12X35)

€ 4.50

8

4311124F00
ref: 8

PEDAL,BRAKE

€ 90.50

9

0916018022
ref: 9

WASHER(18X24X1)

€ 3.00

10

4356124F00
ref: 10

HOOK,RETURN SPRING

€ 8.00

11

0833131186
ref: 11
08331-3118A

CLIP

€ 2.00

12

0944313032
ref: 12

SPRING

€ 4.00
