FRAME COVER (GSX500EE)

GSX500E 1985 (F) GENERAL EXPORT (E01)

Frame cover (gsx500ee) diagram GSX500E 1985 (F) GENERAL EXPORT (E01)

FRAME COVER (GSX500EE) GSX500E 1985 (F) GENERAL EXPORT (E01)
FRAME COVER (GSX500EE) GSX500E 1985 (F) GENERAL EXPORT (E01)
FRAME COVER (GSX500EE) GSX500E 1985 (F) GENERAL EXPORT (E01)
prices are in EUR
ref
part #
description
quantity
1
471104348013Z
ref: 1
COVER, FRAME RH (BLACK)
€ 64.50
2
681304342171P
ref: 2
TAPE SET, FRAME COVER RH
€ 0.00
3
681314360073H
ref: 3
EMBLEM
€ 0.00
4
471104348007P
ref: 4
COVER, FRAME RH (RED)
€ 64.50
5
681304342160D
ref: 5
TAPE SET, FRAME COVER RH
€ 0.00
6
681314360060K
ref: 6
EMBLEM
€ 0.00
7
472104348113Z
ref: 7
COVER, FRAME LH (BLACK)
€ 0.00
8
681404342371P
ref: 8
TAPE SET, FRAME COVER LH
€ 0.00
9
681314360073H
ref: 9
EMBLEM
€ 0.00
10
472104348107P
ref: 10
COVER, FRAME LH (RED)
€ 64.50
11
681404342360D
ref: 11
TAPE SET, FRAME COVER LH
€ 0.00
12
681314360060K
ref: 12
EMBLEM
€ 0.00
13
4711349200
ref: 13
RUBBER,FRAME COVER
4711349200
€ 2.50
14
0932008018
ref: 14
CUSHION
0932008018
€ 4.00
15
0932005006
ref: 15
CUSHION
0932005006
€ 4.00
16
4552204700
ref: 16
GROMMET,SEAT LOCK HOLE
4552204700
€ 4.00
