INNER COVER

GSXR600 2012 (L2) USA (E03)

Inner cover diagram GSXR600 2012 (L2) USA (E03)

INNER COVER GSXR600 2012 (L2) USA (E03)

INNER COVER GSXR600 2012 (L2) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

9441914J00
ref: 1

COVER,BODY COWLING

€ 17.00

2

09409063145PK
ref: 2

CLIP(BLACK)

€ 3.50

3

09409083085ES
ref: 3

CLIP(BLACK)

€ 2.00

4

9446114J00
ref: 4

COWLING,UNDER INNER,R

€ 11.50

5

9446214J00
ref: 5

COWLING,UNDER INNER,L

€ 11.50

6

0940906329
ref: 6

CLIP

€ 3.00

7

9445801H00
ref: 7

COVER,LWR BRACKET

€ 10.00

8

0911106107
ref: 8

BOLT(6X12)

€ 3.00
