prices are in EUR
ref
part #
description
quantity
GEAR & CASE SET,FINAL BEVEL
1
GEAR & CASE SET,FINAL BEVEL
3
STOPPER,FINAL DRIVE BEVEL
4
PLATE,BEARING STOPPER
5
PLATE,BEARING STOPPER
6
O RING(D:2.1,ID:66.2)
7
WASHER(54X68X1.5)
8-1
SHIM,FINAL DRIVE GEAR 62
8-2
SHIM,FINAL DRIVE GEAR 62
8-3
SHIM,FINAL DRIVE GEAR 62
8-4
SHIM,FINAL DRIVE GEAR 62
8-5
SHIM,FINAL DRIVE GEAR 62
9
OIL SEAL
10
COUPLING,FINAL DRIVE GEAR
11
WASHER(16X29X4)
12
NUT
13
STUD 10X25
14
BEARING(20X34X18)
15
BEARING(70X110X13)
16-1
SHIM,DRIVEN GEAR BEARING
16-2
SHIM,DRIVEN GEAR BEARING
16-3
SHIM,DRIVEN GEAR BEARING
16-4
SHIM,DRIVEN GEAR BEARING
17
SEAL,OIL(70X96X16)
18
BEARING(35X48X23.7)
19-1
SHIM,FINAL DRIVEN GEAR
19-2
SHIM,FINAL DRIVEN GEAR
19-3
SHIM,FINAL DRIVEN GEAR
19-4
SHIM,FINAL DRIVEN GEAR
19-5
SHIM,FINAL DRIVEN GEAR
19-6
SHIM,FINAL DRIVEN GEAR
19-7
SHIM,FINAL DRIVEN GEAR
19-8
SHIM,FINAL DRIVEN GEAR
20
RETAINER,FINAL DRIVEN GEAR BRG
21
SCREW 6X12
22
SEAL,OIL(30X42X7)
25
CASE,FINAL GEAR BEARING
26
O-RING
27
BOLT,FINAL DRIVEN GEAR THRUST
31
PLUG (14X12)
32
GASKET(14X19.2X2) (NAS)
34
GASKET(14X19.2X2) (NAS)
35
SPRING
36
CIRCLIP
37
SEAL,OIL(30X40.5X5.5)
40-2
SHAFT,PROPELLER
41
COUPLING,PROPELLER SHAFT
