MAGNETO
GZ250 MARAUDER 2005 (K5) USA (E03)
Magneto diagram GZ250 MARAUDER 2005 (K5) USA (E03)
MAGNETO GZ250 MARAUDER 2005 (K5) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
3210113F00
ref: 1
STARTER ASSY
€ 676.00
2
3210213F01
ref: 2
ROTOR ASSY
€ 469.50
3
0211206253
ref: 3
02112-0625A
SCREW
€ 1.50
4
3179249200
ref: 4
NUT,GENERATOR ROTOR
€ 10.00
5
0834131039
ref: 5
KEY
€ 2.00
6
0713005123
ref: 6
07130-0512B
BOLT
€ 2.50
7
3149745000
ref: 7
CLAMP,GENERATOR LEAD WIRE
€ 1.50
8
0214235083
ref: 8
02142-3508B
SCREW
€ 2.50
9
0940406429
ref: 9
CLAMP(L:45)
€ 2.50
