CARBURETOR (E16)
PV50 1994 (R) (E01)
Carburetor (e16) diagram PV50 1994 (R) (E01)
CARBURETOR (E16) PV50 1994 (R) (E01)
×
prices are in EUR
ref
part #
description
quantity
0
1320017240
ref: 0
CARBURETOR ASSY
€ 0.00
1
0949217004
ref: 1
JET,PILOT (17.5)
€ 8.00
2
0949400757
ref: 2
JET,NEEDLE(E-3)
€ 0.00
3
0949157006
ref: 3
JET, MAIN (57.5)
€ 14.50
4
1325002500
ref: 4
FLOAT
€ 16.50
5
1325420010
ref: 5
PIN,FLOAT
€ 3.00
6
1352346110
ref: 6
GASKET,DRAIN PLUG (NAS)
€ 3.00
7
0211205066
ref: 7
SCREW
€ 2.00
8-1
1339412110
ref: 8-1
MODEL M
CLIP,NEEDLE
€ 3.00
8-2
1339440D00
ref: 8-2
MODEL R
CLIP,NEEDLE
€ 3.00
9
1338317240
ref: 9
NEEDLE,JET
€ 13.00
10
1324705010
ref: 10
PLUG
€ 6.00
11
1324905010
ref: 11
GASKET,DRAIN,PLUG (NAS)
€ 1.50
12
1355117200
ref: 12
VALVE,THROTTLE
€ 0.00
13
1325102410
ref: 13
GASKET (NAS)
€ 4.50
14
1360104148
ref: 14
SCREW
€ 2.50
15
1326701010
ref: 15
SCREW,THROTTLE STOP
€ 6.00
16
1326801010
ref: 16
SPRING
€ 3.50
17
1357346710
ref: 17
SPRING,THROTTLE VALVE RETURN
€ 3.00
18
1358107910
ref: 18
PLATE
€ 6.50
19
1366116600
ref: 19
NUT
€ 5.00
20
1357748110
ref: 20
ADJUSTER,CABLE
€ 8.00
21
1368116600
ref: 21
CAP,RUBBER
€ 7.00
22
1337346710
ref: 22
PLATE,NEEDLE VALVE FITING
€ 4.50
23
0211203066
ref: 23
SCREW
€ 2.00
24
1326917220
ref: 24
SCREW,AIR
€ 0.00
25
1349409410
ref: 25
SPRING
€ 3.00
26
1360647A00
ref: 26
WASHER
€ 2.00
27
1329529900
ref: 27
O RING,PILOT AIR SCREW
€ 4.00
28
1337046710
ref: 28
VALVE ASSY,NEEDLE
€ 44.00
29
1337446710
ref: 29
O RING
€ 4.50
30
1368336A00
ref: 30
L:300ARROW RIGHT85
HOSE
€ 8.00
31
1368336A00
ref: 31
L:300ARROW RIGHT160
HOSE
€ 8.00
