MAGNETO

RB50 1987 (H) (E01)

Magneto diagram RB50 1987 (H) (E01)

MAGNETO RB50 1987 (H) (E01)

MAGNETO RB50 1987 (H) (E01)

prices are in EUR

ref

part #

description

quantity

1

3210128B01
ref: 1
0.6

STARTER ASSY

€ 0.00

2

3212028B00
ref: 2

COIL,LIGHTING

€ 44.00

3

0211204308
ref: 3

SCREW (4X30)

€ 1.50

4

0832121047
ref: 4

WASHER,LOCK 4M

€ 2.00

5

3214028B01
ref: 5

COIL,PRIMARY

€ 59.00

6

0211204208
ref: 6

SCREW

€ 1.00

7

0832121047
ref: 7

WASHER,LOCK 4M

€ 2.00

8

3215028B00
ref: 8

COIL,PICK UP

€ 65.50

9

0211204128
ref: 9

SCREW

€ 1.50

10

0832121047
ref: 10

WASHER,LOCK 4M

€ 2.00

11

3210209401
ref: 11
0.6

ROTOR

€ 0.00

12

0214205128
ref: 12

SCREW

€ 1.50

13

0831616108
ref: 13

NUT

€ 2.00

14

0834131039
ref: 14

KEY

€ 2.00

15

3237130A00
ref: 15

CLAMP,MAGNETO LEAD WIRE

€ 4.50

16

0211206108
ref: 16

SCREW

€ 1.50
