BATTERY

RG125C 1986 (G) (E02 E04 E15 E17 E18 E21 E24 E30)

Battery diagram RG125C 1986 (G) (E02 E04 E15 E17 E18 E21 E24 E30)

BATTERY RG125C 1986 (G) (E02 E04 E15 E17 E18 E21 E24 E30)

BATTERY RG125C 1986 (G) (E02 E04 E15 E17 E18 E21 E24 E30)

prices are in EUR

ref

part #

description

quantity

1

3361002500
ref: 1

BATTERY ASSY(YB4L-B,12V4.2AH)

€ 26.50

2

3365229100
ref: 2

PROTECTOR,20X9

€ 5.00

3

3365137000
ref: 3
CUT AS REQUIRED PROF

PROTECTOR(170X95X3.0)

€ 5.00

4

0946200067
ref: 4

BAND

€ 4.50

5

3368031003
ref: 5

HOSE,BATTERY EXHAUST

€ 4.50

6

0940406405
ref: 6

CLAMP

€ 3.00

7

0940712403
ref: 7

CLAMP

€ 3.00
