CRANKSHAFT

RG125C 1986 (G) (E02 E04 E15 E17 E18 E21 E24 E30)

Crankshaft diagram RG125C 1986 (G) (E02 E04 E15 E17 E18 E21 E24 E30)

CRANKSHAFT RG125C 1986 (G) (E02 E04 E15 E17 E18 E21 E24 E30)
CRANKSHAFT RG125C 1986 (G) (E02 E04 E15 E17 E18 E21 E24 E30)
CRANKSHAFT RG125C 1986 (G) (E02 E04 E15 E17 E18 E21 E24 E30)
prices are in EUR
ref
part #
description
quantity
1-1
1211036A060F0
ref: 1-1
PISTON (54.00MM)
1211036A060F0
€ 58.00
1-2
1211036A06050
ref: 1-2
OPT
PISTON (OS:0.5)
1211036A06050
€ 70.00
1-3
1211036A06100
ref: 1-3
OPT
PISTON(OS:1.0)
1211036A06100
€ 61.00
2-1
1214036A12
ref: 2-1
RING SET, PISTON
1214036A12
€ 40.00
2-2
1214040A10050
ref: 2-2
OPT
RING SET,PISTON(OS:0.50)
1214040A10050
€ 32.00
2-3
1214040A10100
ref: 2-3
OPT
RING SET,PISTO
€ 34.50
3
1215136A00
ref: 3
PIN,PISTON
1215136A00
€ 13.00
4
0938114001
ref: 4
RING,SNAP 14MM
0938114001
€ 1.50
5
0926314022
ref: 5
BEARING(14X18X19.8)
0926314022
€ 10.00
6
0916914007
ref: 6
WASHER
0916914007
€ 7.50
7
1220036A11
ref: 7
CRANKSHAFT ASSY
€ 443.50
8
1216136A10
ref: 8
ROD, CONNECTING
1216136A10
€ 46.50
9
0916022043
ref: 9
WASHER
0916022043
€ 9.50
10
1221136A000A0
ref: 10
PIN,CRANK
1221136A000A0
€ 15.50
11
09263220470B0
ref: 11
ROLLER BEARING (22X28X1
€ 64.00
12
1222036A02
ref: 12
CRANKSHAFT, RH
€ 0.00
13
0621103052
ref: 13
PIN 3X5
0621103052
€ 1.50
14
1226136A02
ref: 14
CRANKSHAFT, LH
€ 0.00
15
0926225049
ref: 15
@l09262-25086
BEARING(25X62X17)
0926225049
€ 28.50
16
1235936A00
ref: 16
SPACER, RH
€ 15.50
17
0928022001
ref: 17
O RING(D:2.4,ID:21.8)
0928022001
€ 2.00
18
0928932003
ref: 18
SEAL,OIL(32X44X8)
0928932003
€ 11.50
19
0928325079
ref: 19
SEAL,OIL(25X36X6)
0928325079
€ 7.50
20
2111136A00
ref: 20
GEAR,PRIMARY DRIVE
€ 41.00
21
0834131059
ref: 21
KEY
0834131059
€ 3.00
22
1745101A01
ref: 22
NT:15
GEAR, WATER PUMP DRIVE
€ 20.00
23
0915912010
ref: 23
NUT
0915912010
€ 4.00
24-1
0918125051
ref: 24-1
SHIM(25X34X0.6)
€ 3.00
24-2
0918125052
ref: 24-2
SHIM(25X34X0.65)
€ 3.00
24-3
0918125053
ref: 24-3
SHIM (25X34X0.7)
€ 3.00
24-4
0918125054
ref: 24-4
SHIM(25X34X0.75)
€ 3.00
24-5
0918125055
ref: 24-5
SHIM (25X34X0.8)
0918125055
€ 2.50
24-6
0918125056
ref: 24-6
SHIM(25X34X0.85)
€ 3.00
24-7
0918125057
ref: 24-7
SHIM(T:0.90)
€ 2.50
24-8
0918125058
ref: 24-8
SHIM(25X34X0.95)
€ 3.00
24-9
0918125059
ref: 24-9
SHIM(25X34X1)
€ 3.50
24-10
0918125060
ref: 24-10
SHIM(25X34X1.05)
€ 3.00
24-11
0918125061
ref: 24-11
SHIM(25X34X1.1)
€ 3.50
24-12
0918125062
ref: 24-12
SHIM(25X34X1.15)
0918125062
€ 3.00
24-13
0918125063
ref: 24-13
SHIM(25X34X1.2)
0918125063
€ 3.50
24-14
0918125064
ref: 24-14
SHIM (T:1.25)
0918125064
€ 3.00
